TRACO POWER THM102411WI medical DC/DC converter
The THM 10WI Series are 10 Watt medical DC/DC converters designed for reliable power conversion in demanding environments like medical equipment, transportation, and control systems. Featuring ultra-wide 4:1 input voltage range, reinforced 5000 VACrms isolation, and low leakage current below 2 μA, these converters meet IEC/EN/ES 60601-1 standards for 2x MOPP. Operating from -40°C to +90°C, with efficiencies up to 89%, they provide high reliability, quick startup, and comprehensive EMC immunity, making them ideal for sensitive medical and industrial applications requiring safety and resilience.
TRACO POWER THM102411WI medical DC/DC converter Specifications:
- Input Voltage Range: 3.3VDC to 48VDC with variants available
- Output Voltage: 3.3V, 5V, 12V, 15V, 24V, 36V, 48V, and dual options
- Output Current: Up to 2500mA depending on model
- Efficiency: Up to 89%
- Isolation Voltage: 5000 VACrms (rated), 250 VACrms working voltage
- Operating Temperature: -40°C to +90°C (derating above 75°C at 3.5%/K)
- Leakage Current: <2 μA
- Start-up Voltage: 4.5V, 9V, 18V depending on model
- Protection: Overload, overvoltage, short circuit; automatic recovery
- Dimensions: Compact DIP-24 plastic case, specific sizes vary by model
- Compliance: IEC/EN/ES 60601-1 3rd edition, IEC 60601-1-2, UL, cUL, RoHS, REACH
- Certifications: 2x MOPP, IEC 60601-1, UL, cUL, EN 55032 EMC compliant
- MTBF: Approximately 3,850,000 hours
- Soldering Temperature: Max 265°C for 10 seconds
Buy the Traco Power THM 10WI – Reliable Medical DC/DC Converter for Industrial Applications
Purchase the Traco Power THM 10WI Series 10 Watt medical DC/DC converter online today. This reliable unit features ultra-wide input voltage, reinforced 5000 VACrms isolation, and a low leakage current under 2 μA. Designed for demanding medical, transportation, and control applications, it operates from -40°C to +90°C with efficiencies up to 89%, ensuring safe and consistent power delivery. Easy to install and certified for safety standards, it’s the ideal choice for high-reliability systems needing robust isolation and compact design.
Order your Traco Power THM 10WI Series 10 Watt medical power supply today and ensure dependable, safe power for critical medical and industrial projects.
Frequently Asked Questions
Where can I buy TRACO POWER THM102411WI?
You can click on the BUY or RFQ button to purchase THM102411WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THM102411WI?
You can download the THM102411WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THM102411WI?
TRACO POWER
