TRACO POWER THM202411WI Medical Power Converter
The THM 20WI series is a high-efficiency medical-grade DC/DC converter delivering 20 watts in a compact 1.6 x 1.0-inch plastic case. It offers ultra-wide 4:1 input voltage range, reinforced isolation of 5000 VACrms, and extremely low leakage current below 2.5 pA. Conforming to IEC/EN/ES 60601-1 3rd edition for 2xMOPP, it features over-temperature protection, a wide operating temperature range from -40°C to 80°C, and immunity to radiated and conducted EMC standards. Suitable for demanding medical, transportation, and control applications requiring reliable power in demanding environments.
TRACO POWER THM202411WI Medical Power Converter Specifications:
- Input Voltage Range: 9 VDC to 36 VDC, 48 VDC models up to 60 V max
- Output Power: 20 W
- Efficiency: up to 89.5%
- Isolation Voltage: 5000 VACrms
- Operating Temperature: -40°C to +80°C, derating above 55°C at 2%/K
- Vibration Resistance: compliant with MIL-STD-810F
- Dimensions: 25.4 mm x 25.4 mm x 13.3 mm (1.00 x 1.00 x 0.52 inches)
- Input Current No Load: 10 mA, Load: 9 mA, Surge Voltage: 60-100 Vmax
- Start-up Voltage: 9 VDC, Under Voltage Lockout: 7.8-8.6 VDC
- Ripple & Noise: 50-75 mVp-p, Transient Response: 250 μs
- Overcurrent Limit: 150% of rated, Overvoltage Protection: 6.2-30 VDC
- Short Circuit: Continuous, automatic recovery
- Protection: Overtemperature at 115°C, Remote On/Off Control (optional)
- Certifications: IEC/EN/ES 60601-1, RoHS, UL Listed
- Housing Material: Non-conductive plastic, Potting: Silicone V-0 rated
- Soldering Temperature: Max 265°C for 10 seconds
Buy the Traco Power Series THM: Medical Power Converter 20W: THM202411WI
Purchase the Traco Power THM202411WI online to ensure reliable, high-efficiency power conversion for medical devices. Compact and robust, this 20W converter features reinforced 5000 VACrms isolation, ultra-wide input range, and low leakage current, making it perfect for healthcare, transportation, and industrial environments. Its certified design conforms to IEC 60601-1, ensuring safety and performance. With a wide operating temperature of -40°C to 80°C and a 5-year warranty, buy online today for a dependable power solution that meets demanding medical standards and enhances your product’s reliability.
Get Traco Power THM202411WI today—built for medical precision and long-lasting durability.
Frequently Asked Questions
Where can I buy TRACO POWER THM202411WI?
You can click on the BUY or RFQ button to purchase THM202411WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THM202411WI?
You can download the THM202411WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THM202411WI?
TRACO POWER
