TRACO POWER THM201211 Medical DC/DC Converter
The THM 20 Series is a 20 Watt medical DC/DC converter range designed for reliable operation in medical equipment, transportation, control, and measurement applications. Encased in a 1.6” x 1.0” plastic casing with wide 2:1 input voltage range, it provides reinforced 5000 VACrms isolation and ultra-low leakage current of less than 2.5 pA. Certified according to IEC/EN/ES 60601-1 3rd edition for 2xMOPP, these converters offer efficiencies up to 90%, operate from -40°C to +80°C, and feature comprehensive EMC compliance, making them ideal for demanding environments.
TRACO POWER THM201211 Medical DC/DC Converter Specifications:
- Input Voltage Range: 5.0 VDC to 48 VDC
- Output Voltage Options: 5 V, 12 V, 15 V, 24 V
- Output Current: 4000 mA to 2000 mA depending on model
- Efficiency: Up to 90%
- Isolation Voltage: 5000 VACrms
- Operating Temperature: -40°C to +80°C
- Ripple and Noise: 75 mVp-p typical at 20 MHz bandwidth
- Dimensions: 25.4 × 25.4 × 10 mm (1.00” × 1.00” × 0.39”)
- Overcurrent Protection: Yes, at 150 % rated load
- Short-circuit Protection: Continuous, automatic recovery
- CSA, IEC/EN/ES 60601-1, EMC compliance to IEC 60601-1-2
- Soldering Temperature: Max. 265°C for 10 seconds
- Humidity Range: 5% to 95% RH non-condensing
- Vibration & Shock Resistance: MIL-STD-810F compliant
- MTBF: Calculated (not specified)
Buy the Buy Traco Power THM 20 Series Part Number THM201211 Online
Purchase the Traco Power THM 20 Series Medical DC/DC Converter online today for a reliable and efficient power solution. With a compact 1.6” x 1.0” plastic case, reinforced 5000 VACrms isolation, ultra-low leakage current, and IEC 60601-1 compliance, this converter ensures safety and durability in demanding environments. Operating from -40°C to +80°C with efficiencies up to 90%, it is ideal for medical equipment, transportation systems, and industrial control. Benefit from fast delivery, trusted quality, and excellent support from authorized distributors.
Get Traco Power THM 20 Series THM201211 today—built for medical-grade reliability, efficiency, and extended range operation.
Frequently Asked Questions
Where can I buy TRACO POWER THM201211?
You can click on the BUY or RFQ button to purchase THM201211 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THM201211?
You can download the THM201211 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THM201211?
TRACO POWER
