TRACO POWER TDR30511SM DC/DC Converter
The TDR 3 series comprises compact 3-watt DC/DC converters designed for space-critical industrial applications. Available in SMD and DIP packages, these highly efficient units operate over a wide input voltage range from 4.5 V to 9 V or 9 V to 18 V, with fully regulated outputs and low ripple noise. They feature high temperature tolerance up to 85°C, isolated inputs of 1600 VDC, continuous short-circuit protection, and remote On/Off control. Ideal for communications, instrumentation, and industrial electronics, they ensure reliable performance even in harsh environments.
TRACO POWER TDR30511SM DC/DC Converter Specifications:
- Input Voltage Range: 4.5~9 VDC or 9~18 VDC depending on model
- Output Voltage: 5 VDC, 12 VDC, 15 VDC, 18-36 VDC, 24 VDC, 36-75 VDC, 48 VDC
- Output Current: 125 mA to 600 mA depending on model
- Efficiency: 79% to 83% depending on model
- Power: 3 Watts
- Operating Temperature: -40°C to +85°C
- Isolation Voltage: 1600 VDC
- Short Circuit Protection: Continuous, automatic recovery
- Ripple and Noise: 30 mVp-p (20 MHz bandwidth)
- Startup Time: 5 ms typical
- Power Frequency Magnetic Field Immunity: 100 A/m
- Soldering Profile (DIP): 265°C / 10 s max
- Environmental Compliance: RoHS, Reach
- Reliability MTBF: >6.2 million hours
- Package: Non-conductive plastic (UL 94V-0 rated), SMD or DIP
Buy the TracoPower TDR 3 Series – Reliable DC/DC Converters for Industrial Applications
Order the TracoPower TDR 3 series DC/DC converter online today and enjoy reliable, high-efficiency power conversion for critical industrial applications. With a compact design available in SMD and DIP packages, these converters deliver fully regulated outputs with minimal ripple noise, ensuring optimal performance even in challenging environments. Featuring wide input voltage ranges, high temperature tolerance up to 85°C, and automatic short-circuit recovery, they are ideal for communication, instrumentation, and industrial electronics requiring space-saving, robust power solutions. Purchase now for fast delivery and dependable operation.
Get TracoPower TDR 3 series today—built for precision, efficiency, and long-lasting durability in industrial electronics.
Frequently Asked Questions
Where can I buy TRACO POWER TDR30511SM?
You can click on the BUY or RFQ button to purchase TDR30511SM from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TDR30511SM?
You can download the TDR30511SM datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TDR30511SM?
TRACO POWER
