TRACO POWER TIM351222SM Medical DC/DC Converter
The TIM 3.5SM series is a compact 3.5 Watt DC/DC converter in SMD packaging designed for medical and industrial applications. It features reinforced isolation of 5000 VACrms, suitable for patient-insulating BF-classifications, with low leakage current under 2 pA, and is certified under IEC/EN/ES 60601-1 3rd edition. Operating across a broad temperature range from -40°C to 90°C, it complies with IEC 60601-1-2 EMC standards. Its highly reliable design includes 5-year warranty, low noise, and robustness for use in medical equipment and sensitive electronic systems.
TRACO POWER TIM351222SM Medical DC/DC Converter Specifications:
- Power: 3.5 Watt
- Isolation Voltage: 5000 VACrms
- Working Voltage: 250 VAC
- Leakage Current: < 2 pA
- Temperature Range: -40°C to 90°C
- Efficiency: up to 83%
- Dimensions: compact SMD package, size varies by model
- Certifications: IEC 60601-1, IEC 60601-1-2
- EMC Compliance: IEC 60601-1-2, EN55032 class A
- Input Voltage Range: model-dependent (e.g., 5V, 9V, 12V, 15V, 24V, 36V, 48V)
- Output Voltage: various options (e.g., 5V, 9V, 12V, 15V, 24V, 36V, 48V)
- Output Current: up to 700 mA depending on model
- Surge Voltage: up to 100 V max
- Start-up Voltage: as low as 4.5V for certain models
- Ripple & Noise: 50-75 mVp-p depending on model
- Reliability: MTBF approx. 5 million hours
- Dimensions: in mm (e.g., length 24.3mm, width 18.1mm)
Buy the Traco Power TIM351222SM – Reliable Medical DC/DC Converter for Industrial Applications
Order the Traco Power TIM351222SM online today and experience the high reliability, medical-grade isolation, and broad temperature operation needed for demanding medical and industrial applications. Engineered for efficiency and safety, this converter provides reinforced 5000 VACrms isolation, ensuring patient safety when used in medical devices. Its compact SMD design allows for easy integration into various electronic equipment, with low leakage current less than 2 pA, ensuring minimal interference. Secure your supply chain and enhance your project’s reliability by purchasing this high-quality DC/DC converter online with confidence today!
Get Traco Power TIM351222SM today—built for medical-grade reliability and long-lasting durability in sensitive electronic systems.
Frequently Asked Questions
Where can I buy TRACO POWER TIM351222SM?
You can click on the BUY or RFQ button to purchase TIM351222SM from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TIM351222SM?
You can download the TIM351222SM datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TIM351222SM?
TRACO POWER
