TRACO POWER TMA1215S DC/DC Converter
The TMA series are miniature, isolated 1 W DC/DC converters in a SIP package, perfect for space-critical applications. They feature single or dual outputs, operate from 5 VDC to 24 VDC, and offer high efficiency up to 81%. Their industry-standard pinout and SMD technology make them cost-effective and easy to install. These converters provide 1000 VDC isolation, operate in temperatures from -40°C to +85°C, and include a 3-year warranty, making them suitable for various board-level power distribution applications in industrial and automation systems.
TRACO POWER TMA1215S DC/DC Converter Specifications:
- Power Output: 1 W
- Input Voltage Range: 5 VDC, 12 VDC, 15 VDC, 24 VDC
- Output Voltages: 5 VDC, 12 VDC, 15 VDC
- Output Current Max: 200 mA (5 V), 84 mA (12 V), 67 mA (15 V)
- Efficiency: Up to 81%
- Isolation Voltage: 1000 VDC
- Operating Temperature Range: -40°C to +85°C
- Storage Temperature: -55°C to +125°C
- Humidity: 95% relative, non-condensing
- Dimensions: Approximately 19.5 mm x 6.5 mm
- Case Material: Non-conductive black plastic, UL 94V-0 rated
- Potting Material: Epoxy
- Soldering Temp: Max 260°C for 10 seconds
- Switching Frequency: 70 to 120 kHz
- Isolation Capacitance: 60 pF typical
- Isolation Resistance: >1,000 MOhm
- MTBF: >2,000,000 hours
- Certifications: RoHS compliant
Buy the Tracopower TMA1215S – Reliable 1W DC/DC Converter for Industrial Applications
Get the Tracopower TMA1215S online today and ensure efficient power management for your industrial applications. Its high efficiency up to 81%, compact SIP package, and 1000 VDC isolation make it ideal for space-sensitive designs. Suitable for operating temperatures from -40°C to +85°C, this 1-watt converter guarantees reliable performance in demanding environments. Benefit from proven quality, RoHS compliance, and a 3-year warranty. Order now and optimize your board-level power distribution with this high-performance DC/DC converter.
Buy Tracopower TMA1215S now and experience unmatched reliability and efficiency in your power conversion needs.
Frequently Asked Questions
Where can I buy TRACO POWER TMA1215S?
You can click on the BUY or RFQ button to purchase TMA1215S from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMA1215S?
You can download the TMA1215S datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMA1215S?
TRACO POWER
