TRACO POWER THN202411 DC/DC Converter Module
The THN 20 Series offers compact, high-performance 20W DC/DC converters with wide input voltage ranges and up to 90% efficiency. Suitable for space-constrained applications, these modules feature an encapsulated steel case, excellent thermal characteristics, and optional heatsinks. They support remote On/Off control, operate reliably from -40°C to +75°C (or up to 85°C with heat sink), and provide galvanic isolation of 1500 VDC. Ideal for battery-powered systems, industrial electronics, and communication equipment needing reliable, efficient power conversion in limited spaces.
TRACO POWER THN202411 DC/DC Converter Module Specifications:
- Input Voltage Range: 12 VDC, 24 VDC, 48 VDC models with surge voltages of 25 V, 50 V, 100 V max
- Output Power: 20W, with adjustable output voltage and up to 90% efficiency
- Operating Temp.: -40°C to +75°C, up to 85°C with heat sink
- Isolation Voltage: 1500 VDC input/output
- Power Management: Remote On/Off, no minimum load requirement
- Ripple & Noise: 75-100 mVp-p (with external capacitor)
- Dimensions: 1.0 x 1.0 x 0.4 inches (25.4 x 25.4 x 10.16 mm)
- Weight: Approx. 15 g
- Certifications: UL 60950-1, EN 60950-1, IEC 60950-1, RoHS compliant
- Thermal & Environmental: Power derating above 70°C, natural convection thermal impedance 17.6 K/W with heat sink, operating humidity 5-95% RH
- Safety & Reliability: MTBF over 1.4 million hours, meets safety standards, includes short circuit, overvoltage, and overcurrent protection
Buy the TracoPower THN-20 Series – Reliable DC-DC Converters for Industrial Applications
Purchase the TracoPower THN-20 Series DC/DC converter modules online to ensure your industrial, communication, or battery systems have efficient, reliable power sources. These 20W power modules feature wide input voltage ranges, high efficiency up to 90%, and a compact size of only 1.0” x 1.0” x 0.4”. They include remote On/Off control, galvanic isolation of 1500 VDC, and operate reliably in temperatures from -40°C to +75°C. Suitable for space-constrained applications, they offer optional heat sinks for higher temperature environments, making them ideal for modern electronic systems requiring robust power conversion.
Get TracoPower THN-20 Series today—built for high efficiency, reliability, and space-saving power conversion solutions.
Frequently Asked Questions
Where can I buy TRACO POWER THN202411?
You can click on the BUY or RFQ button to purchase THN202411 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THN202411?
You can download the THN202411 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THN202411?
TRACO POWER
