TRACO POWER TEN31213 DC-DC Converter
The POWER TEN series includes reliable 3 Watt DC/DC converters designed for industrial and communication systems. Featuring a wide input range, high efficiency up to 84%, and robust full SMD design, these converters offer excellent stability and durability across operating temperatures of -40°C to +85°C. They include short circuit protection, internal filtering to meet EN 55022 and FCC Class A standards, and an isolation voltage of 1500 VDC. Suitable for harsh environments, the series guarantees high MTBF over 1.1 million hours, making them ideal for demanding applications requiring reliable power conversion.
TRACO POWER TEN31213 DC-DC Converter Specifications:
- Input voltage range: 3.3 VDC to 48 VDC
- Output voltage options: 3.3 VDC, 5 VDC, 12 VDC, 15 VDC, 18-36 VDC, 36-72 VDC, 48 VDC
- Maximum output current: 250 mA to 600 mA depending on model
- Efficiency: up to 84%
- Isolation voltage: 1500 VDC
- Operating temperature: -40°C to +85°C
- Ripple and noise: 60 mV peak-to-peak
- Switching frequency: 300 kHz
- MTBF: greater than 1.1 million hours
- Short circuit protection: automatic, indefinite recovery
- Input filtering: meets EN 55022 and FCC Class A standards
- Dimensions: compact, epoxy potting, weighs 12.4g
- Soldering temperature: max 265°C for 10 seconds
Buy the Tracopower TEN 3 Series – Reliable DC-DC Converters for Industrial Applications
Order the Tracopower TEN 3 Series DC-DC converters online today to enhance your power management systems. These high-reliability converters offer efficient, stable power conversion suitable for industrial, communication, and embedded applications. Designed with full SMD technology and robust internal filtering, they meet strict EMI standards and provide excellent thermal performance across a wide temperature range. With features like short circuit protection, isolation voltage of 1500 VDC, and a long MTBF of over 1.1 million hours, they are the perfect solution for demanding environments requiring consistent power supply resilience.
Buy Tracopower TEN 3 Series DC/DC converters now and ensure dependable power supply with high efficiency and extended temperature range.
Frequently Asked Questions
Where can I buy TRACO POWER TEN31213?
You can click on the BUY or RFQ button to purchase TEN31213 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN31213?
You can download the TEN31213 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN31213?
TRACO POWER
