TRACO POWER THL204810WI DC-DC Converter
The THL 20WI series from Traco Power consists of 20W single and dual output DC/DC converters designed for high power density applications. These compact modules feature a durable metal enclosure measuring 1.0" x 1.0" x 0.4", offering efficient heat dissipation and protection. They provide an ultra-wide 4:1 input voltage range, with output voltages precisely regulated for stability. Operating reliably from -40°C to +75°C, extendable to +85°C with heatsinks, they are suitable for mobile, industrial, and communication equipment. Key features include high efficiency up to 90%, remote on/off, 1500VDC isolation, low ripple, and safety certifications, making them ideal for space-conscious designs.
TRACO POWER THL204810WI DC-DC Converter Specifications:
- Dimensions: 1.0" x 1.0" x 0.4" (W x D x H)
- Case Material: Aluminium alloy
- Input Voltage Range: 3.3 VDC to 48 VDC with ultra-wide 4:1 ratio
- Output Voltages: 3.3 VDC, 5 VDC, 12 VDC, 15 VDC, 24 VDC, +12 V, +15 V
- Output Current Max.: 4.5A (3.3V), 4A (5V), 1.67A (12V), 1.34A (15V), 0.835A (24V)
- Efficiency: Up to 90%
- Isolation Voltage: 1500 VDC (input/output, input/case, output/case)
- Operating Temperature Range: -40°C to +75°C, up to +85°C with heatsink
- Ripple & Noise: 75-150 mVp-p depending on model
- Switching Frequency: Approximately 330 kHz
- Protection: Short circuit, automatic recovery, output current limiting
- Remote On/Off: 5-12 VDC or open circuit for ON, 0-1.2 VDC or short for OFF
- Certifications: UL/cUL 60950-1, IEC/EN 60950-1, RoHS compliant
Buy the TracoPower THL204810WI – Reliable High-Efficiency DC-DC for Industrial Applications
Discover the high-performance Traco Power THL204810WI DC-DC converter, offering 20W power in a compact, robust enclosure. With ultra-wide 4:1 input voltage range, up to 90% efficiency, and operating temperature from -40°C to +75°C, this converter ensures reliable power in space-constrained industrial and communication applications. Features include precise output regulation, remote on/off, 1500VDC insulation, low ripple, and safety certifications. Perfect for mobile equipment, instrumentation, distributed power networks, and sensitive electronics needing high reliability and efficiency in demanding environments.
Buy Traco Power THL204810WI now and experience unmatched reliability and space-saving efficiency in industrial electronics.
Frequently Asked Questions
Where can I buy TRACO POWER THL204810WI?
You can click on the BUY or RFQ button to purchase THL204810WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THL204810WI?
You can download the THL204810WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THL204810WI?
TRACO POWER
