TRACO POWER TDN14822WISM DC/DC Power Converter
The TDN 1WISM Series is a compact, high-performance 1 Watt DC/DC power converter in an SMD package measuring 13.2 x 9.1 x 10.2 mm. It features fully regulated outputs, 1600 VDC isolation, and operates reliably from -40°C to +90°C without derating. Designed for space-constrained applications, it offers short circuit protection, remote On/Off, and complies with IEC/EN 62368-1 standards. Suitable for industrial, automation, and electronic systems needing stable power in a small form factor.
TRACO POWER TDN14822WISM DC/DC Power Converter Specifications:
- Dimensions: 13.2 x 9.1 x 10.2 mm
- Power output: 1 Watt
- Input voltage range: 4:1 ratio, nominal models from 3.3 VDC to 48 VDC
- Output voltage options: 3.3 V, 5 V, 9 V, 12 V, 15 V, 24 V, 18 V, 36 V
- Maximum output current varies: from 35 mA to 300 mA depending on model
- Efficiency: 70% to 81% depending on model
- Isolation voltage: 1600 VDC for 60 seconds
- Operating temperature: -40°C to +90°C without derating
- Surge voltage: 25 V to 100 V maximum
- Ripple and noise: 30 mVp-p typical
- Switching frequency: 100 kHz minimum
- Mechanical construction: Non-conducting plastic case, silicone potting (UL 94V-0)
- Weight: 2.7 grams
- Certifications: UL 62368-1, UL 60950-1 safety standards, RoHS compliant
- Isolation capacitance: 50 pF max
- Isolation resistance: > 1 GΩ at 500 V
Buy the Buy Traco Power TDN 1WISM Series Part Number TDN14822WISM Online
Discover the efficient and reliable Traco Power TDN 1WISM Series 1 Watt DC/DC converter, a compact solution designed for demanding applications. Its fully regulated outputs, 1600 VDC isolation, and wide temperature range guarantee performance in space-constrained environments. With short circuit protection, remote On/Off, and compliance with IEC/EN standards, this converter is ideal for industrial, automation, and electronic projects requiring stable power in a small form factor. Order online now to enhance your system’s power management with confidence.
Order your Traco Power TDN 1WISM Series 1 Watt DC/DC converter today and ensure reliable power supply in compact designs for your electronic systems.
Frequently Asked Questions
Where can I buy TRACO POWER TDN14822WISM?
You can click on the BUY or RFQ button to purchase TDN14822WISM from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TDN14822WISM?
You can download the TDN14822WISM datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TDN14822WISM?
TRACO POWER
