TRACO POWER TMH2412D DC/DC Converter
The TRACO POWER Series TMH is a compact, 2 Watt isolated DC/DC converter designed in a SIP package, ideal for space-constrained applications. Offering high efficiency of up to 83%, it features single and dual output options with 1000 VDC isolation, full SMD design, and industry-standard pinouts. The device is fully RoHS compliant, supports wide temperature ranges, and includes a 3-year warranty, making it an excellent choice for board-level power distribution in industrial and electronic systems.
TRACO POWER TMH2412D DC/DC Converter Specifications:
- Power: 2 Watt
- Input Voltage: 5 VDC, 12 VDC, 24 VDC options
- Output Voltage: 5 VDC, 12 VDC, 15 VDC, 24 VDC options
- Output Current Max.: 400 mA (5 V), 165 mA (12 V), 133 mA (15 V), 200 mA (dual)
- Efficiency: Up to 83%
- Isolation Voltage: 1000 VDC
- SMD Design: Yes
- Package: Single-in-line (SIP)
- Operating Temperature: -40°C to +85°C
- Storage Temperature: -50°C to +125°C
- Dimensions: Length 19.5 mm, Width 10.25 mm
- Soldering Temp.: Max +265°C for 10 seconds
- Protection: Reverse voltage limited, short circuit protection
- Certification: RoHS compliant, UL 94 V-0 rated plastic casing
- MTBF: >2,000,000 hours
- Switching Frequency: 50-100 kHz
Buy the Traco Power Series TMH 2 Watt Isolated DC/DC Converter: TMH2412D
Purchase the Traco Power TMH2412D online today to ensure your projects benefit from a compact, reliable, and highly efficient 2 Watt isolated DC/DC converter. With a SIP package, wide temperature range, 1000 VDC isolation, and RoHS compliance, this converter is ideal for space-critical and industrial applications. Fast shipping and dedicated support make it easy to upgrade your power systems with proven, high-quality components that deliver consistent performance and durability in demanding environments.
Buy Traco Power TMH2412D now and experience unmatched reliability and high efficiency in your power conversion applications.
