TRACO POWER TML20124 Power Supply Module
The TML series are compact, fully encapsulated AC/DC power supplies designed for industrial and commercial applications. These modules feature high power density, multiple output options, and universal input voltage ranges from 90-264 VAC. They are equipped with short circuit, overload, and overvoltage protections, meeting safety standards such as UL, CE, and IEC. The series includes models with PCB or chassis mounting options, and offers excellent EMI/RFI filtering with compliance to EN 55022, FCC Level B. Designed for reliability, they operate efficiently within a temperature range of -25°C to +70°C and provide a MTBF of over 200,000 hours.
TRACO POWER TML20124 Power Supply Module Specifications:
- Input Voltage Range: 90-264 VAC or 100-375 VDC
- Input Frequency: 47-440 Hz
- Output Power: 20 & 40 Watt
- Output Voltage Options: 3.3 VDC, 5 VDC, 12 VDC, 15 VDC, 24 VDC, ±5 V, ±12 V, ±15 V
- Ripple and Noise: <0.7% of Vout + 90 mV for 20W models, <50 mVp-p, <1% of Vout for 40W models
- Efficiency: 74-84%
- Operating Temperature Range: -25°C to +70°C (TML 20), -40°C to +60°C (TML 40)
- MTBF: >200,000 hours
- Isolation Voltage: 3000 VAC
- Protection: Short circuit, overload, overvoltage, overtemperature (TML 40 only)
- Certifications: UL, CE, IEC/EN 60950-1, FCC Part 15, Class B EMI
- Casing Material: UL 94V-0 rated plastic resin + fiberglass
- Dimensions: Vary per model, roughly 50-100mm in length/width, weight from 110g to 325g depending on type
- Switching Frequency: 100-132 kHz
Buy the TracoPower Series TML Power Supply: TML20124
Purchase the TracoPower Series TML 20124 power supply online now and benefit from a compact, efficient, and reliable power solution with UL and CE certifications. Designed for industrial and commercial applications, it offers multiple output options, high efficiency, and excellent protections including short circuit and overload safety. With universal input voltage support, operate seamlessly across regions. Trust in the high MTBF of over 200,000 hours and environmental robustness. Get your TML series power module today to ensure your projects’ power needs are met with quality and confidence.
Order your TracoPower Series TML 20124 power supply today and ensure your industrial electronics operate reliably with high efficiency and safety.
Frequently Asked Questions
Where can I buy TRACO POWER TML20124?
You can click on the BUY or RFQ button to purchase TML20124 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TML20124?
You can download the TML20124 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TML20124?
TRACO POWER
