TRACO POWER TEN34823WI DC-DC Converter Module
The TEN 3WI series from TracoPower features 3W single and dual output DC-DC converters in a 24-pin DIP package, suitable for various industrial and communication applications. These converters support a wide 4:1 input voltage range (such as 24VDC or 48VDC) and provide multiple output options including 3.3V, 5V, 12V, 15V, and ±12V, ±15V with respective maximum currents of up to 750mA. They offer high efficiency up to 84%, allowing operation from -40°C to +70°C at full load. Additional features include automatic, indefinite short circuit protection, current limiting, internal filtering compliant with EN 55022-A and FCC Level A standards, 1500VDC I/O isolation voltage, and low ripple noise (75mV peak-to-peak at 20MHz bandwidth). Approved by cUL/UL 60950-1 and IEC/EN 60950-1 safety standards, they measure 20.3mm x 10.2mm x 31.8mm and come with a 3-year warranty.
TRACO POWER TEN34823WI DC-DC Converter Module Specifications:
- Input voltage range: 9-36VDC or 18-75VDC
- Output voltages: 3.3V, 5V, 12V, 15V, and dual ±12V, ±15V
- Output currents: up to 750mA
- Efficiency: up to 84%
- Isolation voltage: 1500 VDC
- Ripple and noise: 75mV peak-to-peak (20MHz bandwidth)
- Operating temperature: -40°C to +70°C
- Full load temperature range: -40°C to +70°C
- Dimensions: 20.3mm x 10.2mm x 31.8mm
- Potting material: Epoxy
- Weight: 12g
- Certifications: UL 60950-1, IEC/EN 60950-1, RoHS compliant
- Surge voltage: up to 100V for 48V models
- Soldering temperature: max 265°C for 10 sec.
- Switching frequency: 350 kHz
Buy the TracoPower TEN 3WI – Reliable DC-DC Converters for Industrial Applications
Purchase the TracoPower TEN 3WI series DC-DC converter module online today to ensure reliable, efficient power conversion for your industrial, communication, and instrumentation projects. With wide input voltage ranges, high efficiency up to 84%, and robust safety standards certification, this converter delivers stable, isolated outputs capable of operating from -40°C to +70°C—perfect for demanding environments. The compact, epoxy-encased design ensures durability and easy integration. Get the trusted power solution you need, backed by a 3-year warranty for long-term peace of mind.
Order your TracoPower SeriesTEN 3WI 3 Watt DC-DC Converter today and give your projects the dependable quality they deserve.
Frequently Asked Questions
Where can I buy TRACO POWER TEN34823WI?
You can click on the BUY or RFQ button to purchase TEN34823WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN34823WI?
You can download the TEN34823WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN34823WI?
TRACO POWER
