TRACO POWER TML20212C Power Module
The TML series are compact, fully encapsulated AC/DC power modules designed for industrial and commercial applications. Offering high power density with models ranging from 20 to 40 Watts, these units feature PCB or chassis mounting options, multiple output configurations, and universal input voltage compatibility (90-264 VAC, 47-440 Hz). They meet international safety standards including UL 60950-1 and IEC 60950-1, with protections against short circuits, overloads, and overtemperatures. Suitable for space-critical designs, they deliver stable output regulation, low ripple, and high efficiency, ideal for electronic equipment requiring reliable power solutions.
TRACO POWER TML20212C Power Module Specifications:
- Power Range: 20W to 40W
- Input Voltage: 90-264 VAC, 47-440 Hz
- Input Current: TM 20 models: 400 mA / 270 mA; TM 40 models: 860 mA / 460 mA
- Leakage Current: 0.75 mA max
- Output Power: Varies by model, up to 26.4W
- Output Voltage & Current: 3.3 V/4500 mA, 5.0 V/4000 mA, 12 V/1670 mA, 15 V/1340 mA, 24 V/840 mA, and dual/triple outputs as specified
- Output Regulation: 0.5% to 7% depending on output and model
- Ripple & Noise: <0.7% of Vout +90 mV, <50 mVp-p, <1% of Vout
- Operating Temperature: 25°C to +60°C with 3% derating above 50°C
- Efficiency: 75-84%
- Isolation Voltage: 3000 VAC
- Protection: Short circuit, overload, overvoltage (120%), temperature (TML 40 only)
- Safety Certifications: UL 60950-1, IEC 60950-1, EN 60950-1
- Enclosure Material: Plastic resin + fiberglass, UL 94V-0 rated
- Switching Frequency: 100 kHz (TML 20), 132 kHz (TML 40)
- Reliability: MTBF >200,000 hours
- Humidity: Max 95% rel., non-condensing
Buy the Buy Traco Power TML Series Power Modules Part Number TML20212C Online
Enhance your electronic systems with the Traco Power TML series power modules, offering 20 to 40 Watts of reliable, efficient power. These compact, fully encapsulated units feature universal input voltage compatibility (90-264 VAC), multiple output options, and robust safety features including UL and IEC certifications. Designed for space-critical applications, they provide low ripple, high regulation accuracy, and excellent thermal performance. Purchase online now to ensure your electronics are powered by a trusted, high-quality power supply that meets international standards and guarantees long-term reliability.
Order your Traco Power TML20212C series high-efficiency power module today and secure reliable power delivery for your industrial electronics projects.
