TRACO POWER THM204813WI Medical Power Converter
This medical-grade DC/DC converter provides 20W power in a compact 1.6 x 1-inch plastic case, certified for IEC/EN/ES 60601-1 standards. It features ultra-wide 4:1 input voltage range, reinforced 5000 VACrms isolation, very low leakage current below 2.5 pA, and operates reliably from -40°C to 80°C. Suitable for medical devices and demanding transportation or measurement applications, it ensures safety, efficiency up to 89%, and long-term durability with a 5-year warranty.
TRACO POWER THM204813WI Medical Power Converter Specifications:
- Input Voltage Range: 9 VDC to 36 VDC, 48 VDC models also available
- Output Voltage: 5 VDC, 12 VDC, 15 VDC, 24 VDC, +5 VDC, +12 VDC, +15 VDC
- Output Current: up to 2000 mA
- Efficiency: Up to 89.5%
- Isolation Voltage: 5000 VACrms
- Leakage Current: < 2.5 pA
- Operating Temperature: -40°C to 80°C
- Start-up Voltage: 9 VDC (or lower), 18 VDC (or lower)
- Peak Surge Voltage: 60 V to 100 Vmax (3 sec)
- Input Current (no load): 10 mA, (full load): 9 mA
- Dimensions: 25.4mm x 25.4mm x 10mm
- Potting Material: Silicone, UL94 V-0 rated
- Certification: IEC/EN/ES 60601-1, ISO 13485, RoHS compliant
- Warranty: 5 years
Buy the Traco Power THM204813WI – Reliable Medical DC/DC Converter for Industrial Applications
Enhance your medical devices with the high-efficiency Traco Power THM204813WI 20W DC/DC converter. Designed for demanding healthcare, transportation, and control systems, it offers reinforced 5000 VACrms isolation, ultra-wide input voltage range, and operation from -40°C to 80°C. Certified for IEC/EN/ES 60601-1, it ensures safety and reliability. With a compact size, low leakage current, and 5-year warranty, this converter is ideal for precise, safe, and durable electronic applications. Purchase online today to upgrade your medical equipment with trusted power solutions.
Buy Traco Power THM204813WI now and experience unmatched reliability and performance in medical and industrial environments.
Frequently Asked Questions
Where can I buy TRACO POWER THM204813WI?
You can click on the BUY or RFQ button to purchase THM204813WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THM204813WI?
You can download the THM204813WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THM204813WI?
TRACO POWER
