TRACO POWER TML20512C Power Module
The TML series offers compact, reliable 20 and 40 watt encapsulated AC/DC power modules suitable for industrial and commercial applications. Designed with high power density and easily mounted on PCB or chassis with screw terminals, these modules support universal input (90-264 VAC, 47-440 Hz). They feature multiple output configurations, including single, dual, and triple outputs, with protections against short circuits, overloads, and overtemperature (for 40 models). Certified for safety standards UL/cUL 60950-1, IEC/EN 60950-1, and compliant with EMI requirements EN 55022, class B, FCC level B, making them ideal for space-critical electronic projects.
TRACO POWER TML20512C Power Module Specifications:
- Power Rating: 20W or 40W
- Input Voltage: 90-264 VAC, 47-440 Hz; 100-375 VDC
- Outputs: Single, dual, and triple configurations
- Output Voltage: 3.3V, 5V, 12V, 15V, 24V, ±5V, ±12V, ±15V
- Output Current: Up to 8A depending on model
- Efficiency: 74% – 84%
- Ripple and Noise: <0.7% of Vout + 90 mV (20W models), <50 mV (40W models)
- Protection: Short circuit, overload, overtemperature (for 40 models)
- Isolation Voltage: 3000 VAC input/output
- Operating Temperature: -25°C to +70°C (20W), -40°C to +60°C (40W)
- Dimensions: Varies by model, approx. 80-97 mm length, 25-50 mm width, 20-30 mm height
- Certifications: UL/cUL 60950-1, IEC/EN 60950-1, EN 55022 B, FCC B
- Protection Class: II (for 40W models)
- MTBF: >200,000 hours
- Environmental: RoHS, Reach compliant
- Mounting: PCB or chassis with screw terminals
Buy the TracoPower TML20512C – Reliable Power Supply for Industrial Applications
Enhance your industrial or commercial electronic setup with the TracoPower TML20512C power module. This high-reliability, compact power supply provides stable output voltages with excellent efficiency, supporting multiple configurations. Its universal input range ensures compatibility worldwide, while protections like short circuit and overload safeguard your equipment. UL and EN safety certifications confirm its quality, making installation straightforward whether mounted on PCB or chassis with screw terminals. Perfect for space-critical applications requiring dependable power for sensitive electronics.
Buy TracoPower TML20512C now and experience unmatched reliability and performance for your industrial electronic projects.
Frequently Asked Questions
Where can I buy TRACO POWER TML20512C?
You can click on the BUY or RFQ button to purchase TML20512C from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TML20512C?
You can download the TML20512C datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TML20512C?
TRACO POWER
