TRACO POWER TDR31213WI Regulated DC-DC Converter
The TDR 3-1213WI from TracoPower is a compact, 3W regulated isolated DC-DC converter designed in a DIP package. It features an ultra-wide input voltage range from 4.5V to 18V DC, providing a stable 15V DC output with a maximum current of 200mA. The converter offers high efficiency of 82% at a switching frequency of at least 100kHz, with no minimum load required, low ripple and noise, and a size of 12.8mm x 8.7mm x 18.9mm. It includes features such as remote ON/OFF control, comprehensive immunity to environmental influences, continuous short circuit protection with automatic recovery, and complies with safety standards UL 60950-1 and UL 94V-0 flammability rating. The device supports input surge voltages up to 25V for 1 second, an input-to-output isolation voltage of 1600VDC for 60 seconds, and an I/O resistance of over 1 GΩ at 500VDC. It operates across temperatures from -40°C to +85°C and provides robust electromagnetic compatibility, including ESD protection up to air ±8kV and contact ±6kV. Ideal for space-constrained high-end applications in communication, instrumentation, and industrial electronics.
TRACO POWER TDR31213WI Regulated DC-DC Converter Specifications:
- Input voltage range: 4.5V to 18V DC
- Output voltage: 15V DC
- Output current: 200mA
- Efficiency: 82% at 100kHz switching frequency
- Isolation voltage: 1600VDC for 60 seconds
- Input surge voltage: up to 25V for 1 second
- Ripple and noise: 30 mVp-p (20 MHz bandwidth)
- Operating temperature: -40°C to +85°C
- MTBF: >5.7 million hours
- Dimensions: 12.8mm x 8.7mm x 18.9mm
- Environmental immunity: ESD up to air ±8kV, contact ±6kV
- Full compliance: UL/CSA 60950-1, RoHS, Reach
- Switching frequency: 100 kHz minimum
- Soldering profile: wave soldering max 265°C / 10s
- Physical casing: UL94V-0 rated plastic
- Isolation resistance: >1 GΩ at 500VDC
- Packaging: Tube of 10 pieces or tape & reel (SMD models)
Buy the TracoPower TDR-3-1213WI – Reliable DC-DC Converter for Industrial Applications
Secure your space-critical applications with the TracoPower TDR-3-1213WI DC-DC converter. This 3W device offers an ultra-wide input voltage range from 4.5V to 18V, delivering a stable 15V output at 200mA with over 80% efficiency. Designed for demanding environments, it features remote ON/OFF control, excellent electromagnetic compatibility, and robust short circuit protection. Its compact size and high reliability make it ideal for communication, industrial electronics, and instrumentation systems. Order online today to ensure high-performance power conversion with proven safety standards and long MTBF.
Buy TracoPower TDR-3-1213WI now and experience unmatched reliability and performance in space-saving industrial power solutions.
Frequently Asked Questions
Where can I buy TRACO POWER TDR31213WI?
You can click on the BUY or RFQ button to purchase TDR31213WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TDR31213WI?
You can download the TDR31213WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TDR31213WI?
TRACO POWER
