TRACO POWER TML40112C Power Module
The TML series are ultra-compact, fully encapsulated AC/DC power modules offering 20 and 40-watt power options, suitable for space-critical industrial and commercial applications. These modules feature universal input 90-264 VAC, high power density, and optional PCB or chassis mounting with screw terminals. They support multiple output configurations, include short circuit and overload protection, meet international safety and EMI standards, and are ideal for automation, control systems, and electronic equipment requiring reliable, efficient power supply solutions. Their rugged design ensures durability in varied environments.
TRACO POWER TML40112C Power Module Specifications:
- Power output: 20W or 40W depending on model
- Input voltage range: 90 - 264 VAC; 100 - 375 VDC
- Input frequency: 47 - 440 Hz
- Output voltage options: 3.3V, 5V, 12V, 15V, 24V, +5V/-5V, +12V/-12V, +15V/-15V, etc.
- Maximum output current: varies by model, e.g., 8A for 3.3V, 4A for 5V, etc.
- Leakage current: 0.75 mA max
- Efficiency: 75% to 84%
- Operating temperature: 25°C to +60°C, de-rating above 50°C
- Protection: Short circuit, overload, overtemperature for TML 40 models
- Isolation voltage: 3000 VAC input to output
- Dimensions: varies by model, e.g., TML 20112C approx. 46.0mm x 22mm x 11mm
- Certifications: UL 60950-1, CE, cUL, certifications for global markets
- Compliance: EN 55022, FCC part 15, EN 55024 EMI standards
- Housing material: Plastic resin with fiberglass, UL 94V-0 rated
- Switching frequency: 100-132 kHz
Buy the TracoPower TML40112C – Reliable Power Module for Industrial Applications
Order the TracoPower TML40112C power module today and experience dependable performance in industrial and commercial electronic systems. This high-density, fully encapsulated power supply delivers 12V with 1.67A maximum load, supporting universal input 90-264VAC, and features robust protection, high efficiency, and compliance with international safety standards. Its compact design fits space-critical applications, making it ideal for automation, control panels, and instrumentation. Purchase online now for quick delivery and guaranteed quality in your power solutions.
Get TracoPower TML40112C today—built for precision and long-lasting durability in demanding industrial environments.
Frequently Asked Questions
Where can I buy TRACO POWER TML40112C?
You can click on the BUY or RFQ button to purchase TML40112C from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TML40112C?
You can download the TML40112C datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TML40112C?
TRACO POWER
