TRACO POWER TMM24112C Medical Power Module
The TMM 24 Series offers fully encapsulated 24 Watt AC/DC power modules with medical safety and industrial safety approvals. Designed for reliable operation from -40°C to +65°C, derating up to 75°C, these modules feature high efficiency, low no-load power (<0.3W), and protection against over-temperature, overload, and short circuits. Suitable for medical, industrial, and transportation applications, they comply with safety standards including 60601-1 and UL 60950-1. Available in PCB or chassis mount versions, they ensure safety and durability in demanding environments with a 3-year warranty.
TRACO POWER TMM24112C Medical Power Module Specifications:
- Power Output: 24 W
- Output Voltage: 24 VDC
- Output Current: 1000 mA
- Input Voltage Range: 85 - 264 VAC
- Input Frequency: 47 - 440 Hz
- Leakage Current: 80 pA typical
- No-load Power Consumption: <0.3 W
- Operating Temperature: -40°C to +65°C, derating above 75°C
- Storage Temperature: -40°C to +95°C
- Protection: Over-temperature, overload, short circuit, automatic recovery
- Isolation Voltage: 4000 VAC input/output
- Efficiency: 83%
- Dimensions: PCB mount or chassis mount options, weight approx. 147 g
- Certifications: UL 60601-1, IEC 60601-1, UL 60950-1, EN 55022, FCC Part 15 Level B
Buy the TracoPower Series TMM: Medical and Industrial 24V Power Module - TMM24112C
Purchase the TracoPower TMM24112C medical power module online today and benefit from high efficiency, low no-load power consumption, and rigorous safety standards. Designed for medical, industrial, and transportation environments, this 24 Watt module provides reliable, safe, and stable power with automatic protection features. Its robust construction and compliance with international safety certifications ensure durability and safety in demanding applications. Ordering online guarantees fast delivery and access to expert support for your power supply needs, making your project both secure and efficient.
Buy TracoPower TMM24112C now and experience unmatched reliability and performance in medical and industrial applications.
Frequently Asked Questions
Where can I buy TRACO POWER TMM24112C?
You can click on the BUY or RFQ button to purchase TMM24112C from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMM24112C?
You can download the TMM24112C datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMM24112C?
TRACO POWER
