TRACO POWER TEX120112 Industrial Power Supply
The TEX 120-112 is a rugged power supply designed for applications in harsh environments. It features a die-cast aluminum housing that is water, ice, oil, and dust-resistant, compliant with IP67 and NEMA 4X standards. The metal casing acts as an efficient heatsink, enabling full power operation at ambient temperatures up to +60°C without the need for a fan. Its shock- and vibration-proof construction allows for direct mounting on machinery. This power supply is suitable for industrial automation and other critical environmental applications. It includes waterproof I/O connectors, an adjustable output voltage, a DC-OK indicator, and provides low ripple and noise, making it ideal for outdoor and demanding industrial use.
TRACO POWER TEX120112 Industrial Power Supply Specifications:
- Input Voltage: 85-264 VAC, 47-63 Hz, 1.0 A at 230 VAC, 2.0 A at 115 VAC
- Output Power: 120 W
- Output Voltage: 12 VDC (adjustable 12-15 V), 24 VDC (adjustable 24-28 V)
- Maximum Output Current: 8.0A for 12 V, 5.0A for 24 V
- Efficiency: 87%
- Operating Temperature Range: -40°C to +85°C, with derating above 60°C
- Housing Material: Die-cast aluminum, IP67, NEMA 4X rated
- Physical Dimensions: 93 x 83 mm, height 56 mm
- Weight: 1000 g
- Connector Type (power input): Binder 3-pin female circular plug
- Connector Type (output): Binder 7-pin male circular plug
- Protection Features: Electronic short circuit, overvoltage, and overcurrent protection
- Certifications: IEC 60950-1, UL 508, IEC 60079-15, UL 61010-1, ATEX, IECEx, CB, RoHS, Reach
- Humidity: Up to 100%, with condensation
- Vibration: IEC 60068-2-6, 3-axis sine sweep 10-55Hz
- Shock: IEC 60068-2-27, 15g half sine, 11ms
- MTBF: >900,000 hours at +40°C
Buy the TracoPower TEX 120 Series – Reliable Industrial Power Supply for Harsh Environments
Explore the robust TracoPower TEX 120 Series power supply designed for demanding industrial applications. With IP67 and NEMA 4X ratings, it effectively withstands water, dust, ice, and oil in harsh environments. Its die-cast aluminum housing doubles as a heatsink, enabling continuous operation without fans up to +60°C. The unit features waterproof connectors, adjustable output voltage, low ripple, and numerous safety approvals including ATEX certification. Purchase online to ensure a reliable, durable power solution suitable for outdoor and industrial automation projects.
Buy TracoPower TEX 120 Series power supply now and experience unmatched reliability and performance in extreme industrial environments.
Frequently Asked Questions
Where can I buy TRACO POWER TEX120112?
You can click on the BUY or RFQ button to purchase TEX120112 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEX120112?
You can download the TEX120112 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEX120112?
TRACO POWER
