TRACO POWER TPP100115AJ Medical Power Supply
The TPP 100A-J series is a 100 watt open frame medical power supply designed for healthcare and industrial applications. It features IEC 60601-1 3rd edition certification, low leakage current below 75 μA, and active power factor correction over 0.95. The power supply offers a high efficiency of up to 92%, a wide input voltage range from 85 to 264 VAC, and a compact 2.0 x 3.0-inch size, making it suitable for space-critical medical devices. Its rugged thermal management ensures reliable performance in demanding environments, including operating at altitudes up to 5000 meters and temperatures from -25°C to +55°C.
TRACO POWER TPP100115AJ Medical Power Supply Specifications:
- Output Power: 100 W
- Input Voltage: AC 85-264 VAC, DC 120-370 VDC
- Output Voltage: 12V, 15V, 24V, 28V, 36V, 48V (adjustable ±10%)
- Output Current: up to 4.17 A for 24V model
- Efficiency: up to 92%
- Low Leakage Current: <75 μA
- Isolation Test Voltage: 5,000 VDC input to output
- Operating Temperature: -25°C to +55°C
- Dimensions: 2.0 x 3.0 inches
- Weight: 156 grams
- Protection Class: I and II
- Compliance: IEC 60601-1, IEC 60950-1, UL 60950-1, EN 60601-1
- Environmental: RoHS, Reach, high reliability
- Altitude: up to 5000 meters
- Power factor correction: >0.95
- Ripple & Noise: 120-190 mVp-p depending on model
- Short Circuit & Overvoltage Protection: Automatic recovery
- Cooling: Natural convection
- Switching Frequency: 45-76 kHz
Buy the Traco Power Series TPP100A-J Medical Power Supply: TPP100115AJ
Get the Traco Power Series TPP100A-J medical power supply online today to secure a high-performance, certified solution for your medical and industrial projects. With IEC 60601-1 compliance, low leakage current, and efficiencies up to 92%, this 100W open frame power supply ensures safety, space-saving design, and reliable operation at high altitudes and within wide temperature ranges. Its compact size, high thermal management, and automatic protections make it ideal for demanding environments. Purchase now to benefit from fast delivery and trusted quality for your medical devices.
Order your Traco Power Series TPP100A-J medical power supply today and ensure reliable, space-efficient power for your critical healthcare equipment.
Frequently Asked Questions
Where can I buy TRACO POWER TPP100115AJ?
You can click on the BUY or RFQ button to purchase TPP100115AJ from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TPP100115AJ?
You can download the TPP100115AJ datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TPP100115AJ?
TRACO POWER
