TRACO POWER TMPS05112 Power Supply Module
The TMPS-05 series offers compact 5W AC/DC power modules in fully encapsulated plastic casings, ideal for space-constrained PCB applications. Certified for household appliances, they meet EN 60335-1 safety standards, with no load input power below 300mW to comply with ErP directives. These modules support wide input voltage ranges (85-264 VAC, 120-370 VDC), featuring efficiency up to 85%. They operate from -25°C to +70°C, have automatic overload protection, short circuit recovery, and a peak current of 130%. Suitable for industrial, IT, and low-power circuits with certifications including UL and EMI compliance.
TRACO POWER TMPS05112 Power Supply Module Specifications:
- Input voltage ranges: AC 85–264 VAC, DC 120–370 VDC
- Input frequency: 47–63 Hz
- Output power max.: 5 Watt
- Output voltage options: 3.3V, 5V, 9V, 12V, 15V, 24V, 48V
- Output current: up to 1515 mA at 3.3V, 1000 mA at 5V, up to 208 mA at 24V, 104 mA at 48V
- Efficiency: up to 85%
- Protection: Over voltage max. 190% of Vout, hiccup short circuit, overload at 150%
- Operating temperature: -25°C to +70°C, derating at 2.5%/K
- Ripple & noise: 60 mVp-p for 3.3V & 5V models, others: 1% max.
- Isolation voltage: 4242 VDC, insulation resistance >100 MOhm
- Switching frequency: 65 kHz typ.
- Physical: Plastic casing, pin-tinned copper, weight 19.7 g
- Certifications: EN 60335-1, UL 60950-1, EMI EN55022 class B
- Protection class: II, safety in IEC/EN 60536
Buy the Traco Power TMPS-05 – Reliable Power Supply for Industrial Applications
Purchase the Traco Power TMPS-05 series online today to ensure reliable, space-efficient power for your industrial, household, or low-power electronics projects. These 5W modules offer high efficiency, wide input voltage ranges, and comprehensive safety certifications including EN 60335-1 and UL. Designed for PCB mounting, they provide overload and short circuit protection, operate from -25°C to +70°C, and comply with ErP directives. A perfect solution for low-power circuits in demanding environments, ensuring operational stability and compliance.
Get Traco Power TMPS-05 series today—built for precision and long-lasting durability in low-power industrial and household solutions.
Frequently Asked Questions
Where can I buy TRACO POWER TMPS05112?
You can click on the BUY or RFQ button to purchase TMPS05112 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMPS05112?
You can download the TMPS05112 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMPS05112?
TRACO POWER
