TRACO POWER TME0305S DC/DC Converter
The TME series comprises compact, 1-watt isolated DC/DC converters in a SIP package, offering high efficiency up to 80% and a broad operating temperature range from -40°C to +85°C. These devices feature industry-standard pinouts, 1000 VDC isolation, and require only 0.7 cm² of board space. They are ideal for generating secondary, isolated voltages in space-constrained applications, with full SMD design, high reliability through 100% parameter testing, and ROHS compliance, supported by a 3-year warranty. Broadband usage spans industrial equipment and control systems needing compact, reliable power conversion solutions.
TRACO POWER TME0305S DC/DC Converter Specifications:
- Input Voltage Range: 3.3 V, 5 V, 12 V, 15 V, 24 V models
- Output Voltage: 3.3 V, 5 V, 9 V, 12 V, 15 V, 24 V
- Maximum Output Current: 260 mA (3.3 V), 200 mA (5 V), 84 mA (12 V, 15 V), 110 mA (9 V)
- Efficiency: Up to 80%
- Isolation Voltage: 1000 VDC
- Operating Temperature: -40°C to +85°C
- Ripple & Noise: 150 mVp-p max at 20 MHz bandwidth
- Switching Frequency: 50 to 110 kHz
- Physical Dimensions: SIP package, approximately 10.16 mm x 7.62 mm (not exact, typical small SIP)
- Soldering Temperature: Up to 265°C for 10 seconds
- Case Material: UL 94V-0 rated black plastic
- Weight: 1.3 g (3.3/5 V models), 1.7 g (24 V model)
- Humidity: Up to 95% non-condensing
- Reliability: MTTF over 2 million hours
- Isolation Capacitance: 60 pF
- Isolation Resistance: >1 GΩ
Buy the Buy TracoPower TME Series Part Number TME0305S Online
Discover the compact and highly efficient DC/DC converter from the TME series, offering 1-watt power output, up to 80% efficiency, and comprehensive 1000 VDC isolation. Its SIP package design enables installation in tight spaces, making it ideal for industrial and automation applications requiring stable isolated voltages. Operates reliably from -40°C to +85°C with low ripple noise, a broad input voltage range, and high safety standards. Purchase online now to enjoy fast delivery, full parameter testing, and ROHS compliance for your power management projects.
Buy TracoPower TME0305S now and experience reliable, space-efficient power conversion for your industrial or control system needs.
Frequently Asked Questions
Where can I buy TRACO POWER TME0305S?
You can click on the BUY or RFQ button to purchase TME0305S from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TME0305S?
You can download the TME0305S datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TME0305S?
TRACO POWER
