TRACO POWER TMR32415WIR DC/DC Converter
The TMR 3WIR series comprises 3 Watt DC/DC converters in a compact SIP-8 metal case, ideal for space-limited applications. Operating from 9-36 VDC or 43-160 VDC with a 4:1 input range, they feature EN 50155 railway approval, UL 60950-1 certification, and 3000 VDC isolation. They provide fully regulated, low-noise outputs, and include short circuit protection, remote On/Off, and high efficiency up to 83%. Their robust design supports operating temperatures from -40°C to +90°C with derating above 78°C, suitable for industrial, railway, and automation applications.
TRACO POWER TMR32415WIR DC/DC Converter Specifications:
- Input Voltage Range: 9-36 VDC or 43-160 VDC with 4:1 wide input ratio
- Output Voltage Options: 15 VDC, 5 VDC, 9 VDC, 24 VDC, 12 VDC, 3.3 VDC, and others
- Output Current Max: 350 mA (depending on model)
- Efficiency: Up to 83%
- Isolation Voltage: 3000 VDC input to output, 1500 VDC input/output to case
- Operating Temperature: -40°C to +90°C with Derating above 78°C
- Ripple & Noise: 75 mVp-p (bandwidth 20 VHz)
- Short Circuit Protection: Yes, automatic recovery
- Remote On/Off: Yes, controlled via open circuit or high impedance
- Mechanical Size: SIP-8 metal case, weight approximately 0.21 kg
- Certifications: EN 50155, UL 60950-1, RoHS, Reach
- Switching Frequency: ~400 kHz
Buy the Traco Power TMR 3WIR – Reliable DC-DC Converter for Industrial Applications
Secure your Traco Power TMR 3WIR 3 Watt DC/DC converter online now for reliable, high-performance power solutions. Designed with a compact SIP-8 case, it offers wide input voltage ranging from 9 to 36 volts or 43 to 160 volts, ideal for industrial environments. Features include EN 50155 railway approval, 3000 VDC isolation, efficient regulation, and short circuit protection. Perfect for space-constrained applications, this converter ensures stable output with low noise and high efficiency, making it the perfect choice for automation, railway, and industrial projects requiring robust power conversion.
Order your Traco Power TMR 3WIR series 3 Watt DC/DC converter today and ensure dependable power supply in your industrial or railway projects.
Frequently Asked Questions
Where can I buy TRACO POWER TMR32415WIR?
You can click on the BUY or RFQ button to purchase TMR32415WIR from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMR32415WIR?
You can download the TMR32415WIR datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMR32415WIR?
TRACO POWER
