TRACO POWER TMR94823 Dual Output Power Converter
The TMR 9-4823 from TracoPower is a high-density, 9W DC-DC converter featuring isolated and fully regulated dual outputs in an 8-pin SIP package. It supports a 2:1 input voltage range from 36VDC to 75VDC and offers an output of ±15VDC with a maximum current of 300mA per rail. This converter has an efficiency of 87%, operates at a switching frequency of 500kHz, and includes features such as remote on/off control, short circuit protection, and no minimum load requirement. Its compact dimensions are 9.6mm x 11.2mm x 21.8mm, making it suitable for space-critical applications in communication equipment and instrumentation. It provides input-to-output isolation of 1500VDC for 60 seconds, with an isolation resistance greater than 1 GΩ and maximum capacitance of 50pF. The device is compliant with EN 55022 class A EMI standards, with an operating temperature range from -40°C to 85°C. It also features robust ESD protection (Air ±8kV, Contact ±6kV) and is certified to UL 60950-1 and IEC/EN 60950-1 for safety. The converter's copper casing is UL 94V-0 rated and is silicone potting for added durability. It is ideal for power management and industrial applications where space and reliability are critical.
TRACO POWER TMR94823 Dual Output Power Converter Specifications:
- Input Voltage Range: 36VDC to 75VDC (2:1 ratio)
- Output Voltage: ±15VDC
- Output Current: 300mA per rail
- Efficiency: 87%
- Switching Frequency: 500kHz
- Isolation Voltage: 1500VDC (60 seconds)
- Isolation Resistance: >1 GΩ
- Isolation Capacitance: 50pF max
- Operating Temperature Range: -40°C to +85°C
- Dimensions: 9.6mm x 11.2mm x 21.8mm
- Casing Material: Copper with UL 94V-0 rating, silicone potting
- ESD Protection: Air ±8kV, Contact ±6kV
- EMC Compliance: EN 55022 Class A
- Safety Certifications: UL 60950-1, IEC/EN 60950-1
- Maximum Capacitance at Start-up: 50pF
- Ripple and Noise: 75mVp-p
- Remote ON/OFF: supported, off current 2-4mA
- Surge Voltage: 36V (12V models), 50V (24V models), 100V (48V models)
Buy the TracoPower TMR94823 – Reliable Dual Output Power Converter for Industrial Applications
Order the TracoPower TMR94823 online today to ensure reliable power delivery for your industrial or communication equipment. Designed with a high-density, compact SIP-8 package, this 9W DC-DC converter features dual regulated outputs, supporting wide input voltage ranges from 36VDC to 75VDC. Its efficiency of 87%, isolating capabilities of 1500VDC, and compliance with safety standards make it ideal for space-critical applications. With remote on/off control and a temperature range of -40°C to +85°C, this converter guarantees long-lasting, stable operation in demanding environments. Purchase online now for fast delivery and exceptional performance in your power management systems.
Get TracoPower TMR94823 today—built for precision and long-lasting durability.
