TRACO POWER TPP150112AJ Medical Power Supply
The TPP 15A-J Series is a compact 15 Watt AC/DC power supply designed for medical applications, meeting IEC 60601-1 standards for 2 x MOPP. It features high efficiency up to 89%, low leakage current below 75 pA, and operates up to 5000 meters altitude. Its full load temperature range is from -40°C to +60°C, with derating to 85°C at 50% load. The power supply ensures EMC compliance and safety, suitable for BF applications with reinforced double isolation. It offers multiple output voltages, including 3.3V, 5V, 9V, 12V, 15V, 24V, 36V, and 48V, with adjustable outputs and a 5-year warranty.
TRACO POWER TPP150112AJ Medical Power Supply Specifications:
- Power: 15 Watts
- Input Voltage: 85-264 VAC, 120-370 VDC (designed for, no certification)
- Input Frequency: 47-63 Hz
- Output Voltage Range: 3.3V to 48V (adjustable ±10%)
- Output Current: Up to 4A depending on model
- Efficiency: up to 89%
- Operational Temperature Range: -40°C to +60°C (full load), derates to 85°C at 50% load
- Protection Class: I and II, reinforced insulation
- Leakage Current: below 75 pA
- Altitude Operation: up to 5000 m
- Certifications: IEC 60601-1, IEC 62368-1, UL 62368-1
- EMC Compliance: IEC 60601-1-2 4th edition
- Dimensions: 1.0” x 2.6” (about 25.4mm x 66mm)
- Isolation Voltage: input to output 5657 VDC, input to case 21121 VDC
- Safety Features: Short circuit, overvoltage, and overload protections
- Installation: Screw hole mounting with optional PE connection
Buy the Traco Power Series TPP15A-J AC/DC Medical Power Supply: TPP150112AJ
Purchase the Traco Power TPP150112AJ Series 15 Watt medical power supply online today and enhance your medical device reliability. Featuring high efficiency, low leakage current, and compliance with IEC 60601-1 safety standards, this power supply guarantees safe operation up to 5000 meters altitude. Its adjustable output voltages cover a broad range suited for various medical applications. With a compact form factor of 1.0” x 2.6”, it ensures easy integration into your equipment. Benefit from temperature robustness, multiple safety protections, and a 5-year warranty by ordering now for dependable, high-performance power solutions.
Order your Traco Power Series TPP150112AJ 15 Watt medical power supply today and ensure reliable performance for your medical devices.
Frequently Asked Questions
Where can I buy TRACO POWER TPP150112AJ?
You can click on the BUY or RFQ button to purchase TPP150112AJ from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TPP150112AJ?
You can download the TPP150112AJ datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TPP150112AJ?
TRACO POWER
