TRACO POWER TRN30523 DC/DC Converter
The TRACO POWER TRN 3 Series is a compact, 3-watt fully regulated DC/DC converter with a cubical 11.9 x 7.7 x 11.0 mm SIP package. It features wide input voltage ranges from 4.5-13.2 V, 9-18 V, 18-36 V, and 36-75 VDC, with 1600 VDC I/O isolation and operates reliably up to 85°C. The converter offers short circuit protection, meets IEC/EN 62368-1 safety standards, and is ideal for space-constrained applications requiring high reliability and efficiency, with an MTBF of 4,400,000 hours.
TRACO POWER TRN30523 DC/DC Converter Specifications:
- Dimensions: 11.9 x 7.7 x 11.0 mm
- Input Voltage Range: 4.5-13.2 V, 9-18 V, 18-36 V, 36-75 VDC
- Output Power: 3 Watts
- I/O Isolation Voltage: 1600 VDC
- Operating Temperature Range: -40°C to +85°C
- Efficiency: 75-84%
- Short Circuit Protection: Yes
- Isolation Resistance: >1 GOhm at 500 VDC
- Safety Standards: IEC/EN 62368-1, UL 60950-1
- MTBF: 4,400,000 hours
- Cooling Method: Convection cooling
- Ripple and Noise: 50 mVp-p
- Switching Frequency: 100 kHz
Buy the Traco Power Series TRN 3 DC/DC Converter: TRN30523
Purchase the Traco Power TRN 3 Series DC/DC converter online today to ensure reliable power conversion for your electronic systems. This 3-watt unit offers a compact SIP package measuring 11.9 x 7.7 x 11.0 mm, delivering fully regulated outputs across wide input voltage ranges from 4.5 to 75 VDC. Designed for high performance and safety, it features a 1600 VDC isolation voltage, operates reliably up to 85°C, and includes short circuit protection. Ideal for applications where space is critical, ensuring efficiency and durability in your power management needs.
Get Traco Power TRN30523 today—built for precision, space-saving design, and long-lasting durability.
Frequently Asked Questions
Where can I buy TRACO POWER TRN30523?
You can click on the BUY or RFQ button to purchase TRN30523 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TRN30523?
You can download the TRN30523 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TRN30523?
TRACO POWER
