TRACO POWER TMDC204811 DC-DC Converter Module
The Traco Power TMDC 20-4811 is a 20W high-performance, single-output DC-DC converter module housed in a fully encapsulated, low-profile plastic case. Designed for industrial and residential applications, it features a 4:1 input voltage range from 18VDC to 75VDC, with an output of 5.1VDC and a maximum current of 4A. The converter offers high efficiency at 90%, a switching frequency of 285 kHz, and does not require a minimum load for operation. It includes a remote on/off control, a status LED indicating output presence, and has certifications aligned with UL, IEC, and CSA standards. The device provides reliable short-circuit protection with hiccup mode, high input/output isolation of 2500VDC, and EMC compliance including ESD protection of ±8kV air and ±4kV contact. It supports operating temperatures from -40°C to 90°C (with derating) and optionally can be mounted via a DIN rail adaptor.
TRACO POWER TMDC204811 DC-DC Converter Module Specifications:
- Input Voltage Range: 18VDC to 75VDC
- Output Voltage: 5.1VDC
- Output Current Max: 4A
- Efficiency: 90%
- Switching Frequency: 285 kHz
- Isolation Voltage: 2500 VDC
- Operating Temperature: -40°C to +90°C (with derating)
- Power Good LED: Yes
- Remote On/Off: Yes
- Short Circuit Protection: Hiccup Mode
- Dimensions: 86.0 mm x 96.0 mm x 25.0 mm
- Weight: 107 g
- EMC Compliance: EN 55032, FCC Part 15 Class A
- Surge Voltage: 50V (24V models), 100V (48V models)
- Input Current at No Load: 35-70 mA
- Isolation Resistance: >1000 MΩ
- Materials: UL 94-0 rated plastic resin
- Certifications: UL, IEC 60950-1, CSA
Buy the TracoSeries TMDC DC-DC Converter: TMDC204811
Secure the Traco Power TMDC 20-4811 online today and enhance your power management system with our high-efficiency, rugged 20W DC-DC converter. Designed for industrial use, it ensures reliable performance across a wide temperature range and provides essential safety and EMC certifications. Featuring remote On/Off control, a power good indicator, and high input/output isolation, this converter meets demanding environmental conditions. Easy to install with optional DIN rail mounting, it's the perfect choice for resilient and efficient power conversion in industrial and residential settings.
Buy Traco Power TMDC204811 now and experience unmatched reliability and performance in industrial power solutions.
Frequently Asked Questions
Where can I buy TRACO POWER TMDC204811?
You can click on the BUY or RFQ button to purchase TMDC204811 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMDC204811?
You can download the TMDC204811 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMDC204811?
TRACO POWER
