TRACO POWER THN302415 DC/DC Converter
The THN 30 Series provides high-performance 30W DC/DC converters with a compact 1.0” x 1.0” x 0.4” metal case, offering extensive features like high efficiency up to 92%, wide input voltage range, and adjustable output voltages. Designed for reliable operation in temperature ranges up to 85°C with optional heatsink, these converters support remote ON/OFF control, high isolation voltage, and low no-load input current. Ideal for space-constrained applications such as mobile equipment, industrial electronics, and distributed power systems, ensuring robust and efficient power conversion.
TRACO POWER THN302415 DC/DC Converter Specifications:
- Power: 30W
- Dimensions: 1.0” x 1.0” x 0.4”
- Input Voltage Range: 3.3 VDC to 75 VDC with models available for 12 V, 24 V, and 48 V
- Output Voltage: 3.3 VDC, 5 VDC, 9-18 VDC, 12 VDC, 15 VDC, 24 VDC, +12 V, +15 V
- Maximum Output Current: 1250 mA to 7000 mA depending on model
- Efficiency: Up to 92%
- Operating Temperature: -40°C to +80°C, up to 85°C with heatsink
- Isolation Voltage: 1500 VDC
- No-load Input Current: as low as 8 mA
- Remote ON/Off Control: 3.0 to 15 VDC or open circuit
- Ripple & Noise: 75 mVp-p (varies by model)
- Switching Frequency: 275 kHz to 330 kHz
- Certifications: UL 60950-1, RoHS 2011/65/EU
- Environmental: RoHS compliant, operating humidity 5-95% non-condensing, thermal impedance 13.8-15.0°C/W
Buy the Traco Power Series THN 30 Power Supply: THN 30-1210
Discover the compact and highly efficient Traco Power Series THN 30-1210 DC/DC converter, delivering 30 watts of power with up to 92% efficiency. Engineered for reliability in demanding industrial and mobile applications, it features a wide input voltage range, low no-load current, and adjustable output voltages for flexible integration. Its small footprint and extensive safety certifications make it ideal for space-constrained environments. Buy online now and enhance your power system with a proven, robust solution designed for longevity and optimal performance.
Order your Traco Power Series THN 30-1210 today and give your projects the dependable quality they deserve, ensuring efficient and space-saving power solutions.
Frequently Asked Questions
Where can I buy TRACO POWER THN302415?
You can click on the BUY or RFQ button to purchase THN302415 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THN302415?
You can download the THN302415 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THN302415?
TRACO POWER
