TRACO POWER TEL104823WI DC/DC Converter
The TEL 10WI Series consists of 10 Watt isolated DC/DC converters in a compact DIP-16 metal package, designed for space-critical applications. Offering high efficiency up to 88% and an ultra-wide 4:1 input voltage range, these converters operate at temperatures from -40°C to +88°C, with a power density of 3.83 W/cm². Equipped with built-in input filters, overload protection, and compliance with EN 55032 class A standards, they are suitable for industrial, instrumentation, and IT applications requiring reliable, low thermal loss power conversion.
TRACO POWER TEL104823WI DC/DC Converter Specifications:
- Power: 10 Watt
- Input Voltage Range: Ultra wide 4:1 input voltage range
- Output Voltage: Various models including 3.3V, 5.1V, 12V, 15V, 24V, 48V, 75V
- Output Current: Up to 2700 mA depending on model
- Efficiency: Up to 88%
- Operating Temperature: -40°C to +88°C
- Isolation Voltage: 1500 VDC input to output
- Dimensions: DIP-16 metal case, 19.2 mm x 11.5 mm x 8 mm
- Weight: 6.5 g
- Isolation Resistance: ≥1 GOhm at 500 V
- Humidity: Up to 95% non-condensing
- Soldering Temperature: Max 260°C for 10 seconds
- Switching Frequency: 355–485 kHz
- Conformance: IEC/EN/UL 60950-1, IEC/EN/UL 62368-1
- Input Filter: Built-in Pi filter
- Protection: Overcurrent, short circuit with hiccup recovery
Buy the Buy Traco Power TEL 10WI Series Part Number TEL104823WI Online
Purchase the Traco Power TEL 10WI series online today to enjoy compact size, high efficiency up to 88%, and excellent thermal performance. These reliable 10W converters feature an ultra-wide input voltage range for diverse applications, built-in EMI filters, and robust protection against short circuits and overloads. Perfect for industrial electronics, instrumentation, and IT systems, the TEL 10WI series ensures stable operation across temperatures from -40°C to +88°C. Buy now for fast delivery and trusted quality.
Buy Traco Power TEL 10WI Series part number TEL104823WI now and experience reliable, high-efficiency power conversion in space-constrained designs.
