TRACO POWER TVN50922WI DC/DC Converter
The TVN 5WI series is a compact, 5-watt DC/DC converter designed for reliable power conversion in industrial and measurement applications. Featuring ultra-low ripple and noise of approximately 10 mVp-p, these converters comply with EN 55032 standards and include a six-sided shielded metal package for excellent EMI suppression. They operate over a wide input voltage range of 4.5-75 VDC, with features such as remote On/Off, over-voltage, and short-circuit protection. Key options include various output voltages like 5V, 12V, 15V, and 24V, with efficiencies up to 88%, making them ideal for audio, instrumentation, and automation systems. Suitable for temperatures from -40°C to +90°C and providing 1,600 VDC isolation, they ensure safe, clean power in demanding environments.
TRACO POWER TVN50922WI DC/DC Converter Specifications:
- Power: 5 Watts
- Input Voltage Range: 4.5-75 VDC
- Output Voltages: 3.3V, 5V, 12V, 15V, 24V, 9-36V dual outputs
- Output Current: up to 1,515 mA depending on model
- Efficiency: up to 89%
- Ripple and Noise: 10 mVp-p typical
- Isolation Voltage: 1,600 VDC
- Operating Temperature: -40°C to +90°C
- Case Temperature: up to 105°C
- Dimensions: ~27.94 mm (1.1 in) x 20 mm (0.79 in)
- Weight: approximately 15.39 g
- Protection: Overvoltage, short circuit, and thermal shutdown
- EMC Compliance: EN 55032 class B, EN 61000-4 series immunity standards
- Soldering Temperature: 265°C / 10 s max.
- Humidity: 5–95% RH non-condensing
- Thermal Impedance: 20°C/W natural convection
Buy the Traco Power Series TVN 5WI DC/DC Converter: TVN50922WI
Experience reliable power conversion with the Traco Power TVN50922WI. This 5-watt DC/DC converter features ultra-low ripple, high efficiency, and wide input voltage range, making it suitable for industrial and measurement systems. With EN 55032 EMI compliance, a robust metal package, and safety features like over-voltage and short-circuit protection, it ensures safe operation across temperatures from -40°C to +90°C. Easy to integrate in automation, audio, and detection circuits, purchase online today and enjoy dependable, stable power supply for your critical projects.
Get Traco Power TVN50922WI today—built for precision and long-lasting durability in demanding electrical environments.
