TRACO POWER TMDC067213H industrial DC/DC converter
The TMDC O6H series is a compact 6-watt industrial DC/DC converter offering a high 2:1 input voltage range from 80 to 160 VDC, reinforced 3000 VAC isolation, and fully regulated single or dual outputs. Designed for harsh industrial environments, it features integrated EMC filters for emission and immunity, operate efficiently from -40°C to +80°C without derating, and includes safety approvals such as UL 62368-1. Its encapsulated plastic case provides durability, safety, and reliable power in demanding industrial and battery applications, ensuring safe SELV outputs and continuous protection against overload, undervoltage, and short circuits.
TRACO POWER TMDC067213H industrial DC/DC converter Specifications:
- Input Voltage Range: 80-160 VDC
- Input Surge Voltage: 170 VDC max. (1 s)
- Output Power: 6 Watts
- Output Voltage Options: 5.1 V, 12 V, 15 V, 24 V, 48 V, ±12 V, ±15 V, ±24 V
- Output Current: 200-1250 mA depending on model
- Efficiency: 82% to 84%
- Isolation Voltage: 3000 VAC reinforced
- Operating Temperature: -40°C to +80°C without derating
- Case Temperature: Max. 105°C
- Dimensions: 44.0 mm x 33.0 mm x 20.5 mm
- Material: UL 94 V-0 rated plastic
- Connection: Screw terminal
- Safety Certifications: UL 62368-1, IEC 62368-1
- EMC Emissions: EN 55032 class A
- EMC Immunity: EN 61000-4 series compliance
- Protection: Overload, undervoltage, short circuit
- Start-up Time: 30 ms typical
- Cooling: Natural convection
- Remote ON/OFF: 3.5 to 12 VDC (Remote On), 0 to 1.2 VDC (Off)
- Weight: 48 g
Buy the Traco Power TMDC-067213H – Reliable Industrial DC/DC Converter for Applications
Purchase the Traco Power TMDC067213H online today—an efficient, rugged 6-watt industrial DC/DC converter delivering reinforced isolation, wide temperature operation, and EMC compliance. Designed for harsh industrial and battery-powered applications, it features a compact plastic encapsulated case with screw terminal connections, ensuring reliable performance and safety. Its high efficiency and integrated protection make it ideal for demanding environments where stable and safe power supplies are essential. Order now to enhance your industrial power solutions with this dependable converter.
Get Traco Power TMDC067213H today—built for precision, durability, and efficient power conversion in industrial environments.
Frequently Asked Questions
Where can I buy TRACO POWER TMDC067213H?
You can click on the BUY or RFQ button to purchase TMDC067213H from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMDC067213H?
You can download the TMDC067213H datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMDC067213H?
TRACO POWER
