Vishay VY2101K29Y5SS63V7 Ceramic Disc Capacitors
Vishay BCcomponents VY2 Series AC Line Rated Ceramic Disc Capacitors offer high reliability and safety across the line. These class X1, 440 Vac, and Y2, 300 Vac capacitors are designed for across-the-line, line bypass, and antenna coupling applications. Featuring ceramic dielectric N750 Y5S, Y5U, YSV, and epoxy resin coating in compliance with UL 94 V-0, they operate from -40°C to +125°C with a climatic category of 40/125/21. The capacitors have radial mounting, with lead spacings of 5.0 mm, 7.5 mm, 10.0 mm, or 12.5 mm, and test voltages up to 2600 Vac, ensuring durability and safety in industrial circuits.
Vishay VY2101K29Y5SS63V7 Ceramic Disc Capacitors Specifications:
- Voltage (Vac): 300, 440
- Capacitance Range: 10 pF to 10,000 pF
- Dielectric: Ceramic N750 Y5S, Y5U, YSV
- Temperature Range: -40°C to +125°C
- Coating: Epoxy resin, UL 94 V-0 flame retardant
- Leakage Current: Insulation resistance of 210000 MΩ
- Test Voltage: 2600 Vac, 50 Hz, 2s for component testing
- Dissipation Factor: Max. 0.5% (Class 1), Max. 2.5% (Class 2)
- Lead Spacing: 5.0 mm, 7.5 mm, 10.0 mm, 12.5 mm
- Dimensions: Body diameter up to 16 mm, lead length 30 mm, thickness varies
- Approval Standards: IEC 60384-14.4, UL 60384-14, DIN EN 60384-14, CSA E60384-1:03
Buy the Vishay VY2 Series U2013 Reliable Ceramic Capacitors for Industrial Applications
Enhance your electrical safety with Vishay VY2 ceramic disc capacitors. Designed for across-the-line and safety applications, these capacitors feature high voltage ratings up to 440 Vac, operate reliably from -40°C to +125°C, and meet strict safety standards. Suitable for industrial equipment, they offer excellent insulation, low dissipation factor, and durable epoxy coating. Purchase online today to secure dependable, UL-listed capacitors that guarantee optimal performance and long-term reliability for your electrical projects.
Order your Vishay Series VY2 ceramic disc capacitors today and ensure high safety and reliability in your industrial circuits.
Frequently Asked Questions
Where can I buy Vishay VY2101K29Y5SS63V7?
You can click on the BUY or RFQ button to purchase VY2101K29Y5SS63V7 from an authorized Vishay distributor.
How do I troubleshoot issues or seek technical support for part VY2101K29Y5SS63V7?
You can download the VY2101K29Y5SS63V7 datasheet or visit the Vishay website for support.
Who is the manufacturer of VY2101K29Y5SS63V7?
Vishay
