WURTH ELEKTRONIK 63910815521CAB Ribbon Flat Cable
The Würth Elektronik 63910815521CAB is a ribbon flat cable designed for use in general electronic equipment. This 8-conductor cable features a 1.27mm pitch and is insulated with PVC. It is compliant with both RoHS and REACH standards, ensuring environmental responsibility. The cable is suitable for applications requiring flexible and space-saving connectivity. Würth Elektronik emphasizes that this cable is not intended for use in high-reliability applications such as aerospace or medical equipment without prior written approval and thorough safety evaluations.
WURTH ELEKTRONIK 63910815521CAB Ribbon Flat Cable Specifications:
- Dimensions: 1.27mm
- Pins: 8
- Pin to Pin (Middle): 8.89 ±0.10 mm
- Length: 10.16 ±0.15 mm
- Pitch: 1.27 mm
- Stranded Wire Section (Metric): 0.89 mm²
- Number on Strand: 7
- Conductor Material: Copper
- Conductor Plating: Tin
- Insulator Material: PVC
- Insulator Color: Grey with Red Marking
- Rated Current: 1 A
- Rated Voltage: 300 V (RMS)
- Withstanding Voltage: 2000 V (AC)
- Insulation Resistance: 10 MΩ
- Signal Delay: 4.65 ns
- Conductor Resistance: 23.7 Ω
- Unbalanced Capacity: 5.6 pF
- Unbalanced Impedance: 105 Ω
- Unbalanced Inductance: 1.45 µH
- RoHS Approval: Compliant [2011/65/EU&2015/863]
- REACh Approval: Conform or declared [(EC)1907/2006]
- cULus Approval: E328849
- Packaging: Bag
- Packaging Unit: 1 piece = 1 Meter
