WAGO 2000409 Double Deck Terminal Block
The WAGO 2000-409 double deck terminal block provides a compact and efficient solution for connecting multiple conductors in a space-constrained environment. Its double-deck design allows for increased circuit density on DIN rails, making it suitable for complex industrial automation and control systems. The Push-in CAGE CLAMP® connection ensures a secure and reliable connection, minimizing the risk of loose connections and downtime. This terminal block is commonly used in power distribution panels, control cabinets, and other industrial applications where reliable and organized wiring is essential.
WAGO 2000409 Double Deck Terminal Block Specifications:
- Rated voltage (III / 3): 690 V
- Rated impulse voltage (III / 3): 6 kV
- Rated current: 24 A
- Rated current (2): 28 A
- Connection technology: Push-in CAGE CLAMP®
- Actuation type: Open Tool Slot
- Connectable conductor materials: Copper
- Nominal cross section: 2.5 mm²
- Solid conductor: 0.25 … 4 mm² / 22 … 12 AWG
- Solid conductor, push-in termination: 0.75 … 4 mm² / 18 … 12 AWG
- Fine-stranded conductor: 0.25 … 4 mm² / 22 … 12 AWG
- Strip length: 10 … 12 mm / 0.39 … 0.47 inch
- Total number of connection points: 2
- Total number of potentials: 2
- Number of levels: 2
- Type of wiring: Front-entry wiring
- Width: 5.2 mm / 0.205 inch
- Height from upper-edge of DIN-35 rail: 51.3 mm / 2.02 inch
- Depth: 80.1 mm / 3.154 inch
- Design: horizontal
- Type of mounting: DIN-35 rail
- Potential marking: L/L
- Marking level: Side marking
- Insulating material: Polyamide 66 (PA 66)
- Fire load: 0.245 MJ
- Weight: 11.749 g
- Product Group: 18 (X-COM-System)
- Country of origin: DE
- GTIN: 4045454916503
- Customs Tariff No.: 85369010000
Buy the 2000-409 WAGO Double Deck Terminal Block | myMectronic
Purchase the WAGO 2000-409 terminal block securely and efficiently online.
Buy Now
Frequently Asked Questions
Where can I buy WAGO 2000409?
You can click on the BUY or RFQ button to purchase 2000409 from an authorized WAGO distributor.
How do I troubleshoot issues or seek technical support for part 2000409?
You can download the 2000409 datasheet or visit the WAGO website for support.
Who is the manufacturer of 2000409?
WAGO
