WAGO 858507 Changeover Relay Module
The WAGO 858-507 relay module is a versatile component designed for various industrial control applications. It offers 4 changeover contacts, allowing for flexible circuit configurations. With a nominal input voltage of 115 VAC and a manual operation feature, this module provides reliable switching capabilities. The integrated red status indicator ensures clear visual feedback on the relay's operational state. Its robust construction and compact design make it suitable for DIN-rail mounting in control cabinets, contributing to efficient and organized automation systems.
WAGO 858507 Changeover Relay Module Specifications:
- Nominal input voltage: 115 VAC
- Input voltage range: -20 … +10 %
- Nominal input current at UN: 10 mA
- Number of changeover/switchover contacts: 4
- Contact material (relay): AgCe
- Limiting continuous current: 5 A
- Inrush current (resistive) (max.): (AC) 15 A / 4 s
- Switching voltage (max.): AC 250 V
- Switching power (resistive) (max.): AC 1250 VA; DC (see load limit curve)
- Recommended minimum load: 12 V / 100 mA
- Pull-in time (typ.): 25 ms
- Drop-out time (typ.): 35 ms
- Bounce time (typ.): 4 ms
- Electrical life (NO; resistive load; 23 °C): 100 x 10 switching operations
- Mechanical life: 20 x 10 switching operations
- Status indicator: Red LED
- Rated voltage: 250 V
- Rated surge voltage: 2.5 kV
- Pollution degree: 2
- Dielectric strength, control/load circuit (AC, 1 min): 1,5 kVrms
- Dielectric strength, open contact (AC, 1 min): 1 kVrms
- Dielectric strength, load/load circuit (AC, 1 min): 1,5 kVrms
- Protection type: IP20
- Connection technology: Push-in CAGE CLAMP®
- Solid conductor: 0,34 … 1,5 mm² / 22 … 16 AWG
- Fine-stranded conductor: 0,34 … 1,5 mm² / 22 … 16 AWG
- Strip length: 9 … 10 mm / 0.35 … 0.39 inch
- Note (conductor cross-section): 2 x 0.34 … 2 x 1.5 mm² / 1 x 2.5 mm² / 2 x 22 … 2 x 16 AWG
- Width: 31 mm / 1.22 inch
- Height from upper-edge of DIN-rail: 73 mm / 2.874 inch
- Depth: 97 mm / 3.819 inch
- Mounting type: DIN-35 rail
- Fire load: 1.225 MJ
- Weight: 96.7 g
- Surrounding air temperature (operation at U )<br>N: -25 … 70 °C
- Surrounding air (operating) temperature for UL: -25 … 50 °C
- Surrounding air temperature (storage): -40 … 80 °C
- Processing temperature: -25 … +50 °C
- Standards and specifications: EN 61010-2-201; EN 61810-1; EN 61373; UL 508 (max. 50 °C)
