WAGO 231110037000 10-pole Female Connector
The WAGO 231-110/037-000 is a versatile 10-pole female connector within the MCS – MULTI CONNECTION SYSTEM. It's designed for universal conductor compatibility and simplifies wiring with vertical and horizontal CAGE CLAMP actuation. Integrated test ports allow for easy circuit testing, and coding fingers ensure proper alignment. This connector is suitable for a wide range of industrial applications requiring secure and efficient connections. Please note that this connector does not have breaking capacity and should be handled according to safety guidelines.
WAGO 231110037000 10-pole Female Connector Specifications:
- Color: gray
- Conductor Size: 2.5 mm²
- Pin Spacing: 5 mm
- Number of Poles: 10
- Nominal Voltage (III/3): 320 V
- Rated Surge Voltage (III/3): 4 kV
- Rated Voltage (III/2): 320 V
- Rated Surge Voltage (III/2): 4 kV
- Nominal Voltage (II/2): 630 V
- Rated Surge Voltage (II/2): 4 kV
- Rated Current: 16 A
- UL Voltage (Use Group B): 300 V
- UL Current (Use Group B): 15 A
- UL Voltage (Use Group D): 300 V
- UL Current (Use Group D): 10 A
- UL Voltage (1977): 600 V
- UL Current (1977): 15 A
- CSA Voltage (Use Group B): 300 V
- CSA Current (Use Group B): 15 A
- CSA Voltage (Use Group D): 300 V
- CSA Current (Use Group D): 10 A
- Connection Technology: CAGE CLAMP®
- Solid Conductor Size: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-Stranded Conductor Size: 0.08 … 2.5 mm² / 28 … 12 AWG
- Ferrule Size: 0.25 … 2.5 mm²
- Strip Length: 8 … 9 mm
- Material Group: I
- Insulation Material: Polyamide 66 (PA 66)
- Flammability Class: V0
- Clamping Spring Material: Chrome nickel spring steel (CrNi)
- Contact Material: Copper alloy
- Contact Plating: tin-plated
- Fire Load: 0.293 MJ
- Weight: 19.1 g
- Operating Temperature Range: -60 … +85 °C
- Width: 66.6 mm
- Height: 14.3 mm
- Depth: 29.6 mm
