WAGO 235404331000 4-pole PCB Terminal Block
The WAGO 235-404/331-000 is a robust 4-pole PCB terminal block designed for secure and efficient connections in a wide range of industrial applications. Its push-button mechanism allows for convenient termination and removal of both solid and stranded conductors, simplifying maintenance and adjustments. The block’s 5/5.08 mm pin spacing ensures compatibility with standard PCB layouts, while its compact design minimizes space requirements. Constructed with high-quality materials like polyamide 66 and electrolytic copper, this terminal block offers excellent durability and performance in demanding environments. It is suitable for use in control cabinets, automation systems, and other electrical installations where reliable power distribution is essential.
WAGO 235404331000 4-pole PCB Terminal Block Specifications:
- Rated voltage (III / 3): 250 V
- Rated impulse voltage (III / 3): 4 kV
- Rated voltage (III / 2): 320 V
- Rated impulse voltage (III / 2): 4 kV
- Rated voltage (II / 2): 630 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 17.5 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 10 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 15 A
- Connection technology: Push-in CAGE CLAMP®
- Actuation type: Push-button
- Solid conductor: 0.2 … 1.5 mm² / 20 … 14 AWG
- Fine-stranded conductor: 0.75 … 1.5 mm² / 20 … 14 AWG
- Fine-stranded conductor with ferrule with plastic collar: 0.25 … 1 mm²
- Fine-stranded conductor with ferrule without plastic collar: 0.25 … 1 mm²
- Strip length: 9 … 10 mm / 0.35 … 0.39 inch
- Conductor entry angle to the PCB: 0 °
- No. of poles: 4
- Total number of connection points: 4
- Total number of potentials: 4
- Number of connection types: 1
- Number of levels: 1
- Pin spacing: 5/5.08 mm / 0.197/0.2 inch
- Width: 21.5 mm
- Height: 19.1 mm
- Height from the surface: 15.5 mm
- Depth: 12.5 mm
- Solder pin length: 3.6 mm
- Solder pin dimensions: 0.4 x 0.8 mm
- Drilled hole diameter (tolerance): 1 mm
- PCB contact: THT
- Solder pin arrangement: over the entire terminal strip, in line
- Number of solder pins per potential: 2
- Color: gray
- Insulating material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Clamping spring material: Chrome nickel spring steel (CrNi)
- Contact material: Electrolytic copper (E) Cu
- Contact plating: tin-plated
- Fire load: 0.056 MJ
- Weight: 3.1 g
- Limit temperature range: -60 … +105 °C
