WAGO 734116 16-pole Female Plug Connector
The WAGO 734-116 is a robust 16-pole female plug connector designed for versatile applications. Its CAGE CLAMP technology simplifies wiring, allowing for both vertical and horizontal actuation. The connector offers strain relief and is protected against mismating, ensuring reliable connections. It is suitable for use in industrial control systems, power distribution, and automation equipment where secure and efficient connections are essential. It is certified to UL, CSA, and EN standards, providing assurance of quality and safety.
WAGO 734116 16-pole Female Plug Connector Specifications:
- Rated voltage (III / 3): 160 V
- Rated impulse voltage (III / 3): 2.5 kV
- Rated voltage (III / 2): 160 V
- Rated impulse voltage (III / 2): 2.5 kV
- Rated voltage (II / 2): 320 V
- Rated impulse voltage (II / 2): 2.5 kV
- Rated current: 10 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 10 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 10 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Connection technology: CAGE CLAMP®
- Actuation type: Operating tool
- Solid conductor: 0.08 … 1.5 mm² / 28 … 14 AWG
- Fine-stranded conductor: 0.08 … 1.5 mm² / 28 … 14 AWG
- Fine-stranded conductor with ferrule with plastic collar: 0.25 … 1.5 mm²
- Fine-stranded conductor with ferrule without plastic collar: 0.25 … 1.5 mm²
- Strip length: 6 … 7 mm / 0.24 … 0.28 inch
- No. of poles: 16
- Total number of connection points: 16
- Total number of potentials: 16
- Number of connection types: 1
- Number of levels: 1
- Pin spacing: 3.5 mm / 0.138 inch
- Width: 58.2 mm / 2.291 inch
- Height: 13.4 mm / 0.528 inch
- Depth: 18.6 mm / 0.732 inch
- Contact type: Female connector/socket
- Mismating protection: Yes
- Color: light gray
- Insulating material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Clamping spring material: Chrome nickel spring steel (CrNi)
- Contact material: Copper alloy
- Contact plating: tin-plated
- Fire load: 0.184 MJ
- Weight: 12 g
- Limit temperature range: -60 … +100 °C
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4044918493901
- Customs Tariff No.: 85366990990
