WAGO 231134001000 4-pole Male Connector
The WAGO 231-134/001-000 is a 4-pole male connector engineered for secure and efficient connections in industrial environments. Designed for vertical PCB mounting, this connector features straight solder pins with a 5mm pin spacing, ensuring compatibility with a wide range of applications. The closed-end design and robust construction contribute to its reliability and prevent mismating. It is suitable for applications requiring stable and reliable power and signal transmission, and its compact size makes it ideal for space-constrained designs. The connector's design allows for nominal current up to 16A, enhancing stability of shorter headers.
WAGO 231134001000 4-pole Male Connector Specifications:
- No. of Poles: 4
- Color: gray
- Ratings according to 1: IEC/EN 60664-1
- Overvoltage category EN 1: III
- Pollution degree (1): 2
- Rated voltage EN (1) [V]: 320
- Rated surge voltage (1) [kV]: 4
- Nominal current [A]: 12
- Solder pin length [mm]: 5
- Solder pin width A [mm]: 1
- Solder pin width B [mm]: 1
- Drilled hole diameter [mm]: 1.4
- Tolerance of drilled hole diameter [mm]: +0.1
- Material group: I
- Insulating material: Polyamide 6.6 (PA 6.6)
- Flammability rating per UL 94: V0
- Lower limit temperature [C]: -60
- Upper temperature limit [C]: 100
- Contact material: Electrolytic copper (Ecu)
- Contact plating: tin-plated
- Fire load [MJ]: 0.026
- Weight [g]: 1.362
- Width [mm]: 23.2
- Width [in]: 0.913
- Height [mm]: 12
- Height [in]: 0.472
- Length [mm]: 8.4
- Length [in]: 0.331
- Pin spacing from [mm]: 5
- Pin spacing up to [mm]: 5
- Pin spacing from [in]: 0.197
- Pin spacing up to [in]: 0.2
