WAGO 231532001000 THT Male Header Connector
The WAGO 231-532/001-000 is a 2-pole THT male header connector designed for reliable PCB connections. It features a 5.08mm pin spacing and angled solder pins, facilitating easy integration into various PCB designs. Constructed with a polyamide 66 insulating material and electrolytic copper contacts, this connector offers excellent electrical and mechanical performance. It is suitable for a wide range of industrial applications requiring robust and secure connections, and is compliant with relevant safety standards. Coding fingers are included for enhanced assembly and error prevention.
WAGO 231532001000 THT Male Header Connector Specifications:
- Pin spacing: 5.08 mm / 0.2 inch
- Width: 13.28 mm / 0.523 inch
- Height: 12.2 mm / 0.48 inch
- Height from the surface: 8.4 mm / 0.331 inch
- Depth: 12 mm / 0.472 inch
- Solder pin length: 3.8 mm
- Solder pin dimensions: 1 x 1 mm
- Drilled hole diameter (tolerance): 1.4 mm (- … +0.1)
- Rated voltage (III / 3): 320 V
- Rated impulse voltage (III / 3): 4 kV
- Rated voltage (III / 2): 320 V
- Rated impulse voltage (III / 2): 4 kV
- Rated voltage (II / 2): 630 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 12 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 10 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage per UL 1977 (factory wiring only): 600 V
- Rated current per UL 1977 (factory wiring only): 10 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 10 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- No. of poles: 2
- Total number of potentials: 2
- Number of connection types: 1
- Number of levels: 1
- Color: orange
- Insulating material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Contact material: Electrolytic copper (E) Cu
- Contact plating: tin-plated
- Fire load: 0.017 MJ
- Weight: 0.8 g
- Limit temperature range: -60 … +100 °C
- Product Group: 3 (Multi Conn. System)
- Packaging type: BOX
- Country of origin: PL
- GTIN: 4044918866774
- Customs Tariff No.: 85366990990
