WAGO 858517 Changeover Relay Module
The WAGO 858-517 relay module is a versatile component for industrial automation and control systems. It provides 4 changeover contacts, ensuring flexibility in circuit design. The gold-plated contacts enhance switching reliability and longevity, while the manual operation feature allows for convenient testing and troubleshooting. A red status indicator provides visual feedback on the relay's operational state. Designed for DIN-rail mounting, this module simplifies integration into existing control panels and offers a robust solution for various electrical applications.
WAGO 858517 Changeover Relay Module Specifications:
- Nominal Input Voltage: 115 VAC
- Input Voltage Range: -20 … +10 %
- Nominal Input Current at UN: 10 mA
- Number of Changeover Contacts: 4
- Contact Material: AgCe + Au
- Limiting Continuous Current: 5 A
- Inrush Current (Resistive): (AC) 15 A / 4 s
- Switching Voltage (Max): AC 250 V
- Switching Power (Resistive): AC 1250 VA; DC (see load limit curve)
- Switching Capacity: AC-15: 1 A / AC 240 V; DC-13: 2 A / DC 24 V
- Recommended Minimum Load: 5 V / 1 mA / 50 mW
- Pull-in Time: 25 ms
- Drop-out Time: 35 ms
- Bounce Time: 4 ms
- Electrical Life (NO): 100 x 10 switching operations
- Mechanical Life: 20 x 10 switching operations
- Rated Voltage: 250 V
- Rated Surge Voltage: 2.5 kV
- Pollution Degree: 2
- Dielectric Strength (Control/Load Circuit): 1.5 kVrms
- Dielectric Strength (Open Contact): 1 kVrms
- Dielectric Strength (Load/Load Circuit): 1.5 kVrms
- Protection Type: IP20
- Connection Technology: Push-in CAGE CLAMP®
- Solid Conductor: 0.34 … 1.5 mm² / 22 … 16 AWG
- Fine-Stranded Conductor: 0.34 … 1.5 mm² / 22 … 16 AWG
- Strip Length: 9 … 10 mm / 0.35 … 0.39 inch
- Width: 31 mm
- Height from Upper-Edge of DIN-Rail: 73 mm
- Depth: 97 mm
- Mounting Type: DIN-35 rail
- Fire Load: 1.225 MJ
- Weight: 95.3 g
- Surrounding Air Temperature (Operation): -25 … 70 °C
- Surrounding Air Temperature (UL): -25 … 50 °C
- Surrounding Air Temperature (Storage): -40 … 80 °C
- Standards/Specifications: EN 61010-2-201; EN 61810-1; EN 61373; UL 508 (max. 50 °C)
