WAGO 231346108000 THT Male Header
The WAGO 231-346/108-000 THT male header is a versatile component designed for secure and reliable connections in various industrial applications. Its 16-pole configuration and 5.08mm pin spacing make it suitable for a wide range of PCB layouts. The threaded flange allows for easy and secure mounting, while the straight design ensures efficient integration into existing systems. Constructed from durable materials like polyamide 66 and electrolytic copper, this header offers excellent performance and longevity. It is commonly used in control cabinets, automation systems, and other industrial environments where robust and dependable connectivity is essential.
WAGO 231346108000 THT Male Header Specifications:
- Color: orange
- Pin spacing: 5.08 mm / 0.2 inch
- Width: 91.28 mm / 3.594 inch
- Height: 17 mm / 0.669 inch
- Height from the surface: 12 mm / 0.472 inch
- Depth: 8.4 mm / 0.331 inch
- Solder pin length: 5 mm
- Solder pin dimensions: 1 x 1 mm
- Drilled hole diameter (tolerance): 1.4 mm (- … +0.1)
- Rated voltage (III / 3): 320 V
- Rated impulse voltage (III / 3): 4 kV
- Rated voltage (III / 2): 320 V
- Rated impulse voltage (III / 2): 4 kV
- Rated voltage (II / 2): 630 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 12 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 10 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage per UL 1977 (factory wiring only): 600 V
- Rated current per UL 1977 (factory wiring only): 10 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 10 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- No. of poles: 16
- Total number of potentials: 16
- Number of connection types: 1
- Number of levels: 1
- Contact type (pluggable connector): Male connector/plug
- Connector connection type: for PCBs
- Mismating protection: No
- Mating direction to the PCB: 90 °
- Locking of plug-in connection: Threaded flange
- PCB contact: THT
- Solder pin arrangement: over the entire male connector, in line
- Number of solder pins per potential: 1
- Insulating material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Contact material: Electrolytic copper (E) Cu
- Contact plating: tin-plated
- Fire load: 0.102 MJ
- Weight: 5.8 g
- Limit temperature range: -60 … +100 °C
- Product Group: 3 (Multi Conn. System)
- Packaging type: BOX
- Country of origin: PL
- GTIN: 4045454029173
- Customs Tariff No.: 85366990990
