WAGO 769110 10-pole Female Plug
The WAGO 769-110 is a 10-pole female plug connector designed for use in various industrial applications. It utilizes WAGO’s innovative CAGE CLAMP® connection technology, ensuring secure and reliable connections. This connector is rated for a voltage of 500V and a current of 32A, making it suitable for a wide range of power distribution and control systems. The plug is designed to accept conductors ranging from 0.08 to 4 mm², offering flexibility in wiring configurations. It is ideal for use in control cabinets, machinery, and other industrial environments where robust and dependable electrical connections are essential.
WAGO 769110 10-pole Female Plug Specifications:
- Rated voltage (III / 3): 500 V
- Rated impulse voltage (III / 3): 6 kV
- Rated current: 32 A
- Connection technology: CAGE CLAMP®
- Actuation type: Operating tool
- Connectable conductor materials: Copper
- Nominal cross section: 4 mm²
- Solid conductor: 0.08 … 4 mm² / 28 … 12 AWG
- Fine-stranded conductor: 0.08 … 4 mm² / 28 … 12 AWG
- Strip length: 8 … 9 mm / 0.31 … 0.35 inch
- No. of poles: 10
- Total number of connection points: 10
- Total number of potentials: 10
- Type of wiring: Front-entry wiring
- Width: 50 mm / 1.969 inch
- Height: 45.2 mm / 1.78 inch
- Depth: 18.3 mm / 0.72 inch
- Module width: 5 mm / 0.197 inch
- Color: gray
- Insulating material: Polyamide 66 (PA 66)
- Fire load: 0.532 MJ
- Weight: 34.1 g
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4044918471787
- Customs Tariff No.: 85366990990
- Contact type (pluggable connector): Female connector/socket
- Connector connection type: for conductors
