WAGO 231604 4 Pole Connector
The WAGO 231-604 is a robust 4-pole connector designed for reliable and efficient power distribution in industrial environments. Featuring a 5mm pitch and utilizing the innovative CAGE CLAMP® connection technology, this connector ensures secure and vibration-resistant terminations. It is suitable for applications requiring a compact and dependable connection solution, offering ease of use and high performance. The connector's design simplifies installation and maintenance, contributing to overall system efficiency and reduced downtime.
WAGO 231604 4 Pole Connector Specifications:
- Product Description: MALE CONNECTOR; 4 POLE; PIN SPACING 5 MM / 0.197 IN; CAGE CLAMP®CONNECTION
- Packing Unit: 100 pieces
- Product Group: 3 (Multi Conn. System)
- Pin Spacing: 5 mm / 0.197 in
- Pole Count: 4
- Cross Section Min: 0.08 mm²
- Cross Section Max: 2.5 mm²
- Cross Section AWG Min: 28 AWG
- Cross Section AWG Max: 12 AWG
- Connection Method: CAGE CLAMP®CONNECTION
- Measured Voltage: 250 V
- Measured Shock Voltage: 4 kV
- Pollution Degree: 3
- Current Intensity: 12 A
- Weight: 6.26 g
- Color: grey
- No. of Connection Points: 4
- No. of Potentials: 4
- Height: 14.3 mm / 0.563 in
- Width: 23.2 mm / 0.913 in
- Depth: 27.5 mm / 1.083 in
- Strip Length Min: 8 mm / 0.33 in
- Strip Length Max: 9 mm / 0.33 in
- Admission Office ABS: 04-HG469925-PDA
- Voltage ABS: 400 V
- Current ABS: 12 A
- Cross Section ABS: 5.0 mm²
- Admission Office BV: 11915/A0
- Voltage BV: 400 V
- Current BV: 16 A
- Cross Section BV: 2.5 mm²
- Admission Office CCA: 5764
- Voltage CCA: 250 V
- Current CCA: 12 A
- Cross Section CCA: 0.08-2.5 mm²
- Admission Office CSA: 154112-1466354
- Voltage CSA: 300 V
- Current CSA: 15 A
- Cross Section CSA: 22-12 AWG
- Admission Office DEMKO: 88126
- Voltage DEMKO: 250 V
- Cross Section DEMKO: 2.5 mm²
- Admission Office GL: 17296-00HH
- Voltage GL: 400 V
- Current GL: 12 A
- Cross Section GL: 5.0 mm²
- Admission Office KEMA: 2083746.02
- Voltage KEMA: 250 V
- Current KEMA: 12 A
- Cross Section KEMA: 0.08-2.5 mm²
- Admission Office KR: HMB05880-EL003
- Voltage KR: 250/400 V
- Current KR: 12/16 A
- Cross Section KR: 2.5 mm²
- Admission Office LR: 96/20035
- Voltage LR: 400 V
- Current LR: 12 A
- Cross Section LR: 5.0 mm²
- Admission Office NEMKO: P94101840
- Voltage NEMKO: 250 V
- Cross Section NEMKO: 2.5 mm²
- Admission Office RMR: 11130002
- Voltage RMR: 400 V
- Current RMR: 12 A
- Cross Section RMR: 5.0 mm²
- Admission Office UR: E45171
- Voltage UR: 600 V
- Current UR: 15 A
- Cross Section UR: 12 AWG
- Admission Office UR2: E45172
- Voltage UR2: 300 V
- Current UR2: 15 A
- Cross Section UR2: 22-12 AWG
