WAGO 20021304 3-conductor Terminal Block
The WAGO 2002-1304 is a robust 3-conductor through terminal block specifically engineered for use in hazardous environments, meeting Ex e II and Ex i application requirements. It utilizes WAGO’s Push-in CAGE CLAMP® technology for secure and efficient connections. Designed for DIN-rail 35 x 15 and 35 x 7.5 mounting, this terminal block is ideal for industrial control panels and machinery where reliable power distribution is critical. It supports a nominal voltage of 800V and a rated current of 24A, ensuring dependable performance in demanding applications. The blue color and side/center marking options enhance organization and identification within electrical systems.
WAGO 20021304 3-conductor Terminal Block Specifications:
- Electrical data: Subject to changes. Refer to product documentation.
- Nominal voltage (III/3): 800 V
- Rated surge voltage (III/3): 8 kV
- Rated current: 24 A
- Rated current 2: 32 A
- Ratings legend: (III / 3) ≙ Overvoltage category III / Pollution degree 3
- Rated voltage UL (Use Group B): 600 V
- Rated current UL (Use Group B): 20 A
- Rated voltage UL (Use Group C): 600 V
- Rated current UL (Use Group C): 20 A
- Rated voltage CSA (Use Group B): 600 V
- Rated current CSA (Use Group B): 20 A
- Rated voltage CSA (Use Group C): 600 V
- Rated current CSA (Use Group C): 20 A
- Rated voltage EN (Ex e II): 550 V
- Rated current (Ex e II): 22 A
- Rated current (Ex e II) with jumper: 20 A
- Connection technology: Push-in CAGE CLAMP®
- Actuation type: Push-in
- Connectable conductor materials: Copper
- Nominal cross-section: 2,5 mm²
- Solid conductor: 0,25 … 4 mm² / 22 … 12 AWG
- Solid conductor; push-in termination: 0,75 … 4 mm² / 18 … 12 AWG
- Fine-stranded conductor: 0,25 … 4 mm² / 22 … 12 AWG
- Fine-stranded conductor; with insulated ferrule: 1 … 2,5 mm² / 18 … 12 AWG
- Fine-stranded conductor; with ferrule; push-in termination: 1 … 2,5 mm² / 18 … 12 AWG
- Strip length: 10 … 12 mm / 0.39 … 0.47 inch
- Total number of connection points: 3
- Total number of potentials: 1
- Number of levels: 1
- Wiring type: Front-entry wiring
- Note (conductor cross-section): Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.
- Number of jumper slots: 2
- Width: 5,2 mm / 0.205 inch
- Height from upper-edge of DIN-rail: 32,9 mm / 1.295 inch
- Depth: 59,2 mm / 2.33 inch
- Design: horizontal type
- Mounting type: DIN-35 rail
- Marking level: Center/side marking
- Color: blue
- Insulation material: Polyamide 66 (PA 66)
- Fire load: 0.104 MJ
- Weight: 6.2 g
- Product Group: 22 (TOPJOB S)
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4017332999243
- Customs tariff number: 85369010000
