WAGO 231605114000 5-pole Male Connector
The WAGO 231-605/114-000 is a robust 5-pole male connector within WAGO's Multi Connection System. It offers a universal connection solution for all conductor types, simplifying wiring processes. The innovative CAGE CLAMP actuation allows for both vertical and horizontal wiring, facilitating easy cable pre-assembly and on-unit wiring. This connector is ideal for wire-to-wire and board-to-wire connections in industrial automation, control panels, and power distribution systems. It is designed for reliable performance and ease of use, contributing to efficient and safe electrical installations.
WAGO 231605114000 5-pole Male Connector Specifications:
- Color: gray
- Material group: I
- Insulation material: Polyamide 66 (PA 66)
- Rated voltage (III/3): 320 V
- Rated surge voltage (III/3): 4 kV
- Rated voltage (III/2): 320 V
- Rated surge voltage (III/2): 4 kV
- Rated voltage (II/2): 630 V
- Rated surge voltage (II/2): 4 kV
- Rated current: 12 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 15 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage UL (1977): 600 V
- Rated current UL (1977): 15 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 15 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Connection technology: CAGE CLAMP®
- Actuation type: Operating tool
- Solid conductor: 0,08 … 2,5 mm² / 28 … 12 AWG
- Fine-stranded conductor: 0,08 … 2,5 mm² / 28 … 12 AWG
- Fine-stranded conductor with insulated ferrule: 0,25 … 1,5 mm²
- Fine-stranded conductor with uninsulated ferrule: 0,25 … 2,5 mm²
- Strip length: 8 … 9 mm / 0.31 … 0.35 inch
- Pole No: 5
- Total number of connection points: 5
- Total number of potentials: 5
- Number of connection types: 1
- Number of levels: 1
- Conductor entry direction to mating direction: 0 °
- Pin spacing: 5 mm / 0.197 inch
- Width: 46 mm / 1.811 inch
- Height: 17,5 mm / 0.689 inch
- Depth: 27,5 mm / 1.083 inch
- Housing sheet thickness: 0,5 … 2,5 mm / 0.02 … 0.098 inch
- Mounting type: Snap-in
- Mounting type 2: Feed-through mounting
- Contact type (pluggable connector): Male connector/plug
- Connector (connection type): for conductor
- Mismating protection: No
- Flammability class per UL94: V0
- Clamping spring material: Chrome nickel spring steel (CrNi)
- Contact material: Electrolytic copper (E Cu)
- Contact plating: tin-plated
- Fire load: 0.203 MJ
- Weight: 9.9 g
- Limit temperature range: -60 … +100 °C
- Product Group: 3 (Multi Conn. System)
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4050821216032
- Customs tariff number: 85366990990
