WAGO 231634 4-pole Male Connector
The WAGO 231-634 is a versatile 4-pole male connector designed for a wide range of electrical applications. Its innovative CAGE CLAMP actuation simplifies wiring, allowing for both vertical and horizontal cable insertion. This connector is suitable for connecting various conductor types and is ideal for wire-to-wire and board-to-wire connections. It offers robust electrical ratings, including a rated voltage of 320V and a rated current of 12A, and is compliant with RoHS standards. The connector's design facilitates easy integration into various systems and is supported by a range of compatible accessories like insulation stops and coding keys.
WAGO 231634 4-pole Male Connector Specifications:
- Color: orange
- Pin spacing: 5.08 mm
- Number of poles: 4
- Rated voltage (III / 3): 320 V
- Rated impulse voltage (III / 3): 4 kV
- Rated voltage (III / 2): 320 V
- Rated impulse voltage (III / 2): 4 kV
- Rated voltage (II / 2): 630 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 12 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 15 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage per UL 1977 (factory wiring only): 600 V
- Rated current per UL 1977 (factory wiring only): 15 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 15 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Connection technology: CAGE CLAMP®
- Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor with ferrule with plastic collar: 0.25 … 1.5 mm²
- Fine-stranded conductor with ferrule without plastic collar: 0.25 … 2.5 mm²
- Strip length: 8 … 9 mm
- Total number of connection points: 4
- Total number of potentials: 4
- Number of connection types: 1
- Number of levels: 1
- Conductor entry direction to mating direction: 0 °
- Width: 23.52 mm
- Height: 14.3 mm
- Depth: 27.5 mm
- Contact type: Male connector/plug
- Mismating protection: No
- Insulating material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Clamping spring material: Chrome nickel spring steel (CrNi)
- Contact material: Electrolytic copper (E Cu)
- Contact plating: tin-plated
- Fire load: 0.11 MJ
- Weight: 6.5 g
- Limit temperature range: -60 … +100 °C
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4044918259811
- Customs Tariff No.: 85366990990
