WAGO 231634109000 4-pole Male Connector
The WAGO 231-634/109-000 is a 4-pole male connector designed for versatile applications. It utilizes the innovative CAGE CLAMP® connection technology, enabling easy cable pre-assembly and on-unit wiring through both vertical and horizontal actuation. The threaded flange provides secure mounting options, while the design supports wire-to-wire and board-to-wire connections. It is rated for voltages up to 320V and currents up to 12A, and is UL, CSA, and KEMA certified, ensuring reliable performance in industrial environments. The connector is constructed with durable materials like polyamide 66 and chrome nickel spring steel, offering excellent insulation and mechanical strength.
WAGO 231634109000 4-pole Male Connector Specifications:
- Color: orange
- Rated voltage (III / 3): 320 V
- Rated impulse voltage (III / 3): 4 kV
- Rated voltage (III / 2): 320 V
- Rated impulse voltage (III / 2): 4 kV
- Rated voltage (II / 2): 630 V
- Rated impulse voltage (II / 2): 4 kV
- Rated current: 12 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 15 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage per UL 1977 (factory wiring only): 600 V
- Rated current per UL 1977 (factory wiring only): 15 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 15 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Connection technology: CAGE CLAMP®
- Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
- Fine-stranded conductor with ferrule with plastic collar: 0.25 … 1.5 mm²
- Fine-stranded conductor with ferrule without plastic collar: 0.25 … 2.5 mm²
- Strip length: 8 … 9 mm / 0.31 … 0.35 inch
- No. of poles: 4
- Total number of connection points: 4
- Total number of potentials: 4
- Number of connection types: 1
- Number of levels: 1
- Pin spacing: 5.08 mm / 0.2 inch
- Width: 30.22 mm / 1.19 inch
- Height: 14.3 mm / 0.563 inch
- Depth: 27.5 mm / 1.083 inch
- Contact type (pluggable connector): Male connector/plug
- Mismating protection: No
- Locking of plug-in connection: Threaded flange
- Insulating material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Clamping spring material: Chrome nickel spring steel (CrNi)
- Contact material: Electrolytic copper (E Cu)
- Contact plating: tin-plated
- Fire load: 0.121 MJ
- Weight: 6.8 g
- Limit temperature range: -60 … +100 °C
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4044918283076
- Customs Tariff No.: 85366990990
