WAGO 231704037000 4-pole Female Plug Connector
The WAGO 231-704/037-000 is a versatile 4-pole female plug connector within the MCS – MULTI CONNECTION SYSTEM. It's designed for universal conductor types and offers easy cable pre-assembly and on-unit wiring thanks to its vertical and horizontal CAGE CLAMP actuation. The connector includes integrated test ports for convenient testing and coding fingers for proper alignment. It's suitable for a wide range of industrial applications requiring reliable and efficient connections, and is compliant with various safety standards. Always observe the further product documentation for proper usage and safety guidelines.
WAGO 231704037000 4-pole Female Plug Connector Specifications:
- Color: orange
- Pin spacing: 7.62 mm
- Pole No.: 4
- Total number of connection points: 4
- Total number of potentials: 4
- Rated voltage (III/3): 500 V
- Rated surge voltage (III/3): 6 kV
- Rated voltage (III/2): 630 V
- Rated surge voltage (III/2): 6 kV
- Nominal voltage (II/2): 1000 V
- Rated surge voltage (II/2): 6 kV
- Rated current: 16 A
- Rated voltage UL (Use Group B): 300 V
- Rated current UL (Use Group B): 15 A
- Rated voltage UL (Use Group D): 300 V
- Rated current UL (Use Group D): 10 A
- Rated voltage UL (1977): 600 V
- Rated current UL (1977): 15 A
- Rated voltage CSA (Use Group B): 300 V
- Rated current CSA (Use Group B): 15 A
- Rated voltage CSA (Use Group D): 300 V
- Rated current CSA (Use Group D): 10 A
- Connection technology: CAGE CLAMP®
- Solid conductor: 0,08 … 2,5 mm² / 28 … 12 AWG
- Fine-stranded conductor: 0,08 … 2,5 mm² / 28 … 12 AWG
- Fine-stranded conductor with insulated ferrule: 0,25 … 1,5 mm²
- Fine-stranded conductor with uninsulated ferrule: 0,25 … 2,5 mm²
- Strip length: 8 … 9 mm
- Material group: I
- Insulation material: Polyamide 66 (PA 66)
- Flammability class per UL94: V0
- Clamping spring material: Chrome nickel spring steel (CrNi)
- Contact material: Copper alloy
- Contact plating: tin-plated
- Fire load: 0.179 MJ
- Weight: 9.7 g
- Limit temperature range: -60 … +85 °C
- Packaging type: BOX
- Country of origin: DE
- GTIN: 4044918376525
- Customs tariff number: 85366990990
